GPIB-PCIIB Interface Card
Introduction: PCI-Based GPIB Connectivity for Instrument Control
The GPIB-PCIIB is a high-performance GPIB (IEEE 488) interface card designed for installation in standard PCI bus slots. It offers reliable and fast communication between a host computer and GPIB-enabled instruments, streamlining automated test and measurement processes in laboratory and industrial environments.
Key Features & Specifications
| Feature | Specification |
|---|---|
| Interface Type | IEEE 488 (GPIB) via PCI |
| Data Transfer Rate | Up to 1.2 MB/s |
| Number of GPIB Devices | Up to 14 |
| Connector | 24-Pin IEEE 488 Standard |
| Operating System Compatibility | Windows, Linux |
| Isolation | 2500V RMS |
| Operating Temperature | 0°C to 55°C |
Why It Matters
- PCI Bus Integration: Ensures seamless connectivity for desktop systems with PCI slots.
- Streamlined Data Transfer: Up to 1.2 MB/s throughput for fast and efficient instrument communication.
- Broad Compatibility: Ideal for labs and facilities running Windows or Linux OS.
Alternative Models from Other Manufacturers
| Feature | GPIB-PCIIB | National Instruments PCI-GPIB | Keysight 82350B | ICS Electronics 488-PCI |
|---|---|---|---|---|
| Interface Type | IEEE 488 (PCI) | IEEE 488.2 (PCI) | IEEE 488.2 (PCI) | IEEE 488 (PCI) |
| Data Transfer Rate | Up to 1.2 MB/s | Up to 1.8 MB/s | Up to 1.5 MB/s | Up to 1 MB/s |
| Number of GPIB Devices | Up to 14 | Up to 14 | Up to 14 | Up to 14 |
| Operating System Compatibility | Windows, Linux | Windows, Linux | Windows | Windows, Linux |
| Operating Temperature | 0°C to 55°C | 0°C to 50°C | 0°C to 55°C | -10°C to 60°C |
Customer Testimonials
"The GPIB-PCIIB has been a reliable solution for connecting multiple lab instruments without the need for external converters." - Test Engineer
"Installation and setup were straightforward, and data transfer is consistently fast and error-free." - Electronics Lab Manager
User Manual & Documentation
For complete setup instructions, configuration, and troubleshooting, please refer to the official GPIB-PCIIB User Manual.
Conclusion & Final Recommendation
The GPIB-PCIIB interface card offers reliable, high-speed GPIB communication through the PCI bus, making it a great choice for modernizing test stations or building new automated measurement systems.
Order the GPIB-PCIIB today to enhance your laboratory or industrial test setups with robust GPIB connectivity!
