National Instruments PS-10 Desktop AC-to-DC power supply

1 image: Click to enlarge

National Instruments · CompactDAQ; CompactRIO

NI PS-10 Desktop DC Power Supply

The NI PS-10 is a 24 VDC, 5 A, 120 W desktop power supply for supported CompactDAQ and CompactRIO systems in laboratory and test-bench setups.

ManufacturerNational Instruments

ModelPS-10

Part Number782698-01

Product TypeDesktop AC-to-DC power supply

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: PS-10

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

DC output24 VDC, 5 A

Rated power120 W

AC input100–120 VAC or 200–240 VAC

Output connectionBare wire

NI part number782698-01

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

The PS-10 provides external DC power for supported NI CompactDAQ and CompactRIO equipment used with a desktop computer in a lab or on a test bench. NI identifies it as a desktop supply rated at 24 VDC, 5 A and 120 W.

Its bare-wire output supports direct wiring to the target system's power connection. NI recommends desktop supplies for desktop prototyping rather than deployment on industrial factory floors; check the target controller or chassis accessory guide before selecting a supply.

24 VDC output rated for 5 A and 120 W.
Accepts 100–120 VAC or 200–240 VAC input.
Bare-wire output for direct connection to supported controller power terminals.
Desktop format intended for laboratory, test-bench and desktop prototyping use.

Verified specifications

Technical data

Verified product specifications.

Output voltage	24 VDC
Rated output current	5 A
Rated output power	120 W
AC input voltage ranges	100–120 or 200–240 VAC
DC output termination	Bare wire

Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Product brand

CompactDAQ / CompactRIO

Supported system families; model-specific compatibility applies

PS-10

External desktop DC power supply

System connection

Bare-wire DC output for connection to supported system power terminals.

Check the exact controller or chassis accessory guide and power-terminal wiring before connection. Desktop supplies are not intended for factory-floor deployment.

Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI PS-10 Product PageOfficial Product Page · ni.com

Open →

CompactDAQ External Power SuppliesAccessory Compatibility Guide · ni.com

Open →

CompactRIO Power Supply AccessoriesAccessory Compatibility Guide · ni.com

Open →

Powering Your CompactDAQ or CompactRIO SystemTechnical resource

Open →

Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping

Free Shipping. Full policy terms apply.

Warranty

30-Day Warranty. Standard coverage applies.

Returns

30-Day Returns. Return policy applies.

Price / Availability

Contact SOHO ProLab for current quote and availability.

Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Alternatives & system components

Explore equipment

Test Equipment Parts & Accessories

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

What are the PS-10 output ratings?

NI rates the PS-10 at 24 VDC, 5 A and 120 W.

How does the PS-10 connect to the powered system?

The DC output terminates in bare wire for direct connection to the supported system's power terminals. Follow the target system's wiring instructions.

Is the PS-10 supported by every CompactDAQ chassis?

No. Compatibility is model-specific. NI lists the PS-10 for cDAQ-9132 through cDAQ-9139 controllers, for example, but lists no external power supply for the cDAQ-9171.

Is the PS-10 intended for factory-floor deployment?

NI describes its desktop power supplies as suitable for desktop prototyping, not industrial factory-floor deployment.
