The NI USRP-2922 is a Gigabit Ethernet software defined radio covering 400 MHz to 4.4 GHz with one transmit and one receive channel. It does not include GPS-disciplined clocking.
Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.
Key product information and technical features.
Within the NI USRP family, the USRP-2922 pairs the N210 platform with an SBX RF front end. Its single transmit/receive channel arrangement distinguishes it from dual-channel USRP models.
NI-USRP 2022 Q4 explicitly lists this model as supported and documents LabVIEW integration. Select the driver and application software together using the release-specific support table.
Verified product specifications.
| Transmit and receive frequency range | 400 MHz to 4.4 GHz |
|---|---|
| RF channel count | 1 transmit / 1 receive |
| Maximum instantaneous bandwidth, 16-bit sample width | 20 MHz |
| Maximum instantaneous bandwidth, 8-bit sample width | 40 MHz |
| Maximum I/Q sample rate, 16-bit sample width | 25 MS/s |
| Maximum I/Q sample rate, 8-bit sample width | 50 MS/s |
| External DC power requirement | 6 V, 3 A |
Confirm condition, included accessories and revision before ordering.
Confirmed per unit.
Device / accessories confirmed in quote.
Exact revision confirmed when relevant.
Review system components and compatibility requirements.
Manufacturer
Radio platform and host interface
N210-based radio with SBX RF front end
NI-USRP 2022 Q4 lists LabVIEW 2019, 2020, 2021, and 2022 Q3 support for USRP-2922.
Manuals, software and technical resources for this model.
Review shipping, warranty and return terms before ordering.
Choose pricing, rental or repair for this exact model.
Product-specific answers based on available technical information.
No. NI documents Gigabit Ethernet as its host interface.
NI specifies 20 MHz at 16-bit sample width and 40 MHz at 8-bit sample width. Actual throughput depends on the host and network.
Both cover 400 MHz to 4.4 GHz with one transmit and one receive channel. The USRP-2932 includes GPS-disciplined clocking; the USRP-2922 does not.
