National Instruments USB-6009 OEM OEM multifunction data acquisition device
1 image: Click to enlarge
National Instruments · USB DAQ

USB-6009 OEM

The NI USB-6009 OEM is a USB multifunction DAQ device for integration into larger systems. It combines analog input and output, digital I/O and event counting with an OEM 34-pin interface.

ManufacturerNational Instruments
ModelUSB-6009 OEM
Product TypeOEM multifunction data acquisition device
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: USB-6009 OEM

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Analog inputs8 single-ended or 4 differential
Input resolution14-bit differential; 13-bit single-ended
Maximum sampling48 kS/s aggregate, system dependent
OEM connection34-pin header
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The USB-6009 measurement architecture supports voltage acquisition, software-timed analog output and digital signal monitoring or control. Its maximum input sampling rate is shared across the active analog input channels.

The OEM version uses a 34-pin connector for system integration. Consult the OEM guide for mounting, pin assignments and differences from the enclosed USB-6009.

  • Selectable differential or single-ended analog input configuration.
  • Two 12-bit analog outputs with software-timed updates.
  • Twelve individually configurable digital I/O lines.
  • One 32-bit counter for falling-edge event counting.
Verified specifications

Technical data

Verified product specifications.

Analog input channels8 single-ended or 4 differential
Analog input resolution14 differential; 13 single-ended bit
Maximum aggregate sample rate48, system dependent kS/s
Analog outputs2 channels, 12-bit resolution
Maximum analog output update rate150, software-timed Hz
Analog output range0 to +5 V
Digital I/O12 individually programmable lines
Event counter1 counter, 32-bit, falling-edge counting
OEM I/O connector34-pin 3M N2534-6002RB header
OEM dimensions87.6 × 57.2 × 15.5 mm
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

USB

Host interface

USB-6009 OEM

Integrated multifunction DAQ component

Integration reference

Use the OEM guide alongside the USB-6008/6009 measurement documentation.

The end-system supplier is responsible for compliance; NI makes no safety, EMC or CE compliance claims for this OEM component.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI USB-6008/6009 OEM User GuideOEM User Guide · download.ni.com
Open →
NI USB-6008/6009 User GuideMeasurement And Operation Guide · download.ni.com
Open →
USB-6009 SpecificationsSpecifications; Apply OEM Exceptions · download.ni.com
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Related products

Alternatives & system components

Related model
USB-6009View product →
Related model
USB-6008 OEMView product →
FAQ

Product-specific questions

Product-specific answers based on available technical information.

Does every input configuration provide 14-bit resolution?

No. Differential acquisition provides 14-bit resolution; single-ended acquisition provides 13-bit resolution.

Does the OEM version expose the +2.5 V output?

No. The OEM guide explicitly excludes the +2.5 V output.
