National Instruments USB-6008 OEM Board-level multifunction data acquisition device
1 image: Click to enlarge
National Instruments · USB DAQ

USB-6008 OEM

The NI USB-6008 OEM is a board-level multifunction USB DAQ device for integration into a larger system. It combines analog input and output, digital I/O and an event counter.

ManufacturerNational Instruments
ModelUSB-6008 OEM
Part Number193132-02
Product TypeBoard-level multifunction data acquisition device
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: USB-6008 OEM

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Analog inputs8 single-ended or 4 differential
Input resolution12-bit differential; 11-bit single-ended
Maximum sampling10 kS/s aggregate, system dependent
Analog outputs2 channels, 12-bit
Digital I/O12 individually configurable lines
OEM connection34-pin header
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

This OEM version provides the USB-6008 measurement functions without the standard enclosure. Its board-level interface supports integration into custom equipment rather than screw-terminal bench wiring.

  • Software-selectable single-ended or differential analog input configuration.
  • Software-timed voltage outputs spanning 0 to +5 V.
  • 32-bit falling-edge event counter.
  • Motherboard mounting through a mating board socket.
Verified specifications

Technical data

Verified product specifications.

Analog input channels8 single-ended or 4 differential
Analog input resolution12 differential; 11 single-ended bits
Maximum aggregate input sample rate10; system dependent kS/s
Analog outputs2 channels
Analog output resolution12 bits
Maximum analog output update rate150; software-timed Hz
Analog output range0 to +5 V
Digital I/O12 lines
Event counter1 counter, 32-bit resolution
OEM dimensions87.6 × 57.2 × 15.5 mm
OEM I/O connector34-pin 3M four-wall header, N2534-6002RB
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

USB

Host interface

USB-6008 OEM

Board-level DAQ component

Integration documentation

Use the OEM guide for connector assignments and mechanical details.

The OEM device has no +2.5 V output. Final-system compliance is the end-product supplier's responsibility.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI USB-6008/6009 OEM User GuideOEM User Guide · download.ni.com
Open →
USB-6008 SpecificationsSpecifications; Apply OEM Exceptions · ni.com
Open →
NI USB-6008 Product and Variant InformationManufacturer Product Page · ni.com
Open →
OEM Pinout, Mounting and USB Connection InstructionsTechnical resource
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Related products

Alternatives & system components

Related model
USB-6008View product →
Related model
USB-6009 OEMView product →
FAQ

Product-specific questions

Product-specific answers based on available technical information.

Does 10 kS/s apply to each analog input?

No. It is the maximum aggregate input sample rate and is system dependent.

Can both USB connection paths be used simultaneously?

No. NI specifies using either the board's USB connector or the USB signals on the 34-pin connector, not both.
