National Instruments SWB-2817 Matrix relay card

1 image: Click to enlarge

National Instruments · NI SwitchBlock

SWB-2817

The National Instruments SWB-2817 is a 16×22 reed-relay matrix card for NI SwitchBlock. It requires a PXI Carrier Module for SwitchBlock rather than installing directly as a stand-alone PXI module.

ManufacturerNational Instruments

ModelSWB-2817

Product TypeMatrix relay card

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: SWB-2817

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Matrix16 rows × 22 columns

Relay technologyReed

Maximum switching current0.25 A

CarrierPXI-2800 required

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

The SWB-2817 belongs to NI's modular SwitchBlock matrix-switching platform. Each card occupies one relay-card position in a carrier, allowing matrix capacity to be assembled from individual cards.

The PXI-2800 carrier occupies four PXI slots, holds up to six SwitchBlock matrix modules, and provides an integrated analog bus for combining matrices. Cable selection and the card's A/B variant should be checked before planning external row connections.

1-wire matrix topology.
Uses one SwitchBlock relay-card position.
Supports carrier-based matrix expansion through the SwitchBlock analog bus.

Verified specifications

Technical data

Verified product specifications.

Topology	1-wire 16 × 22 matrix
Maximum switching voltage, row-to-column	100 VDC / 70 VAC
Maximum switching current per channel	0.25 A
Maximum carry current per channel	0.3 A
Maximum switching power per channel and per crosspoint	3 W
Relay type	Reed
I/O connector	96-position plastic SCSI

Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

NI SwitchBlock / PXI-2800

Modular switching platform and required carrier

SWB-2817

16×22 matrix relay card

Software identification

SwitchBlock cards appear in NI MAX or NI-SWITCH as NI model-number A/B variants rather than SWB model names.

Requires a SwitchBlock carrier; confirm the A/B variant and connector pinout before wiring.

Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI 2817 SpecificationsSpecifications · download.ni.com

Open →

SwitchBlock Modules: Switches Cable and Accessory CompatibilityCompatibility Guide · ni.com

Open →

NI SwitchBlock Hardware ArchitectureTechnical resource

Open →

Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping

Free Shipping. Full policy terms apply.

Warranty

30-Day Warranty. Standard coverage applies.

Returns

30-Day Returns. Return policy applies.

Price / Availability

Contact SOHO ProLab for current quote and availability.

Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Alternatives & system components

Explore equipment

Electronic Test and Instrumentation

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Can the SWB-2817 be used directly in a PXI chassis?

No. It requires the PXI-2800 Carrier Module for SwitchBlock and is not a stand-alone PXI module.

Is 0.3 A the switching-current rating?

No. Maximum switching current is 0.25 A per channel; 0.3 A is the maximum carry current. The 3 W switching-power limit also applies.

Does every SWB-2817 have external row access?

The NI 2817A/B pinout differs: analog-bus pins are connected on the A variant and marked no-connect on the B variant. Confirm the installed variant before planning external row access.
