NI (National Instruments) SWB-2816 8x46, 0.3 A, Reed Matrix Module for SwitchBlock

1 image: Click to enlarge

NI (National Instruments) · Computer-Based Device

SWB-2816

The NI SWB-2816 is an 8x46 reed relay matrix module with 368 crosspoints for SwitchBlock systems. It operates in 1-wire mode for configurable signal routing.

ManufacturerNI (National Instruments)

ModelSWB-2816

Part Number781420-16 · 781421-16

Product Type8x46, 0.3 A, Reed Matrix Module for SwitchBlock

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: SWB-2816

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Number of Columns46

Maximum Switching Current DC0.25 A

Maximum Switching Voltage DC100 V

Relay TypeReed

Number of Rows8

Mode (n-wire)1-wire

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

The SWB-2816 provides 8 rows and 46 columns of reed relay switching in a 1-wire matrix. Its 368 crosspoints support connecting inputs to outputs individually or in combination.

Within a SwitchBlock system, the matrix can route signals to different test points on a unit under test and change connection paths without manually changing external connections. The listed NI part numbers are 781420-16 and 781421-16.

8x46 matrix configuration with 368 crosspoints.
Reed relays with a listed switch bandwidth of 8 MHz.
1-wire routing with individual or combined input-to-output connections.
Maximum switching voltage of 100 V DC or 70 V AC.
Maximum DC switching current of 0.25 A; maximum AC carry current of 0.3 A.

Verified specifications

Technical data

Verified product specifications.

Number of Columns	46
Maximum Switching Current DC	0.25 A
Maximum Switching Voltage DC	100 V
Relay Type	Reed
Number of Rows	8
Mode (n-wire)	1-wire
Supported Hardware Platform	Computer-Based Device
Bus Connection	Switchblock
Crosspoints	368
Maximum Carry Current AC	0.3 A
Maximum Switching Voltage AC	70 V
Switch Bandwidth	8 MHz
NI part numbers	781420-16, 781421-16

Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

NI

Manufacturer

Computer-Based Device

Supported Hardware Platform

SWB-2816

This product

Platform shown as listed by NI. Confirm controller, chassis and software fit for your system with NI before integration.

Manuals & software

Technical resources

Manuals, software and technical resources for this model.

Specifications (NI)Specifications · ni.com

Open →

Dimensional Drawings (NI)Dimensional Drawings · ni.com

Open →

Product Page (NI)Product Page · ni.com

Open →

Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping

Free Shipping. Full policy terms apply.

Warranty

30-Day Warranty. Standard coverage applies.

Returns

30-Day Returns. Return policy applies.

Price / Availability

Contact SOHO ProLab for current quote and availability.

Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Explore equipment

Electronic Test and Instrumentation

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

What matrix configuration does the SWB-2816 provide?

It provides 8 rows and 46 columns, giving 368 crosspoints in 1-wire mode.

What are the maximum DC switching ratings?

The listed maximum DC switching current is 0.25 A, and the maximum DC switching voltage is 100 V. Consult the NI specifications for operating conditions and applicable limits.

Is the 0.3 A rating the DC switching current?

No. The preserved specifications list 0.3 A as the maximum AC carry current. The maximum DC switching current is 0.25 A.

What are the NI part numbers for the SWB-2816?

The listed part numbers are 781420-16 and 781421-16. The supplied data does not distinguish their ordering configurations.

What signal-routing function does the matrix provide?

The matrix can connect any input to any output individually or in combination, allowing connection paths to change without manually changing external connections.
