NI (National Instruments) SWB-2815 4x86, 0.3 A, Reed Matrix Module for SwitchBlock

1 image: Click to enlarge

NI (National Instruments) · Computer-Based Device

SWB-2815

The NI SWB-2815 is a 4-row by 86-column reed relay matrix module for SwitchBlock. It provides 344 crosspoints for 1-wire signal routing.

ManufacturerNI (National Instruments)

ModelSWB-2815

Part Number781420-15 · 781421-15

Product Type4x86, 0.3 A, Reed Matrix Module for SwitchBlock

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: SWB-2815

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Number of Columns86

Maximum Switching Current DC0.25 A

Maximum Switching Voltage DC100 V

Relay TypeReed

Number of Rows4

Mode (n-wire)1-wire

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

The SWB-2815 is a reed relay matrix module with 4 rows, 86 columns, and 344 crosspoints. It operates in 1-wire mode and uses a SwitchBlock bus connection.

The matrix supports dynamic signal routing within test systems, connecting inputs to outputs individually or in combination. Its routing role includes connecting instruments such as oscilloscopes, DMMs, arbitrary waveform generators, and power supplies to test points on a unit under test.

4 × 86 matrix configuration with 344 crosspoints for 1-wire routing.
Reed relays with a maximum DC switching current of 0.25 A and maximum DC switching voltage of 100 V.
Maximum AC carry current of 0.3 A and maximum AC switching voltage of 70 V.
Switch bandwidth of 6 MHz.
SwitchBlock interface for matrix-based instrument signal routing.

Verified specifications

Technical data

Verified product specifications.

Number of Columns	86
Maximum Switching Current DC	0.25 A
Maximum Switching Voltage DC	100 V
Relay Type	Reed
Number of Rows	4
Mode (n-wire)	1-wire
Supported Hardware Platform	Computer-Based Device
Bus Connection	Switchblock
Crosspoints	344
Maximum Carry Current AC	0.3 A
Maximum Switching Voltage AC	70 V
Switch Bandwidth	6 MHz
NI part numbers	781420-15, 781421-15

Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

NI

Manufacturer

Computer-Based Device

Supported Hardware Platform

SWB-2815

This product

Platform shown as listed by NI. Confirm controller, chassis and software fit for your system with NI before integration.

Manuals & software

Technical resources

Manuals, software and technical resources for this model.

Specifications (NI)Specifications · ni.com

Open →

Dimensional Drawings (NI)Dimensional Drawings · ni.com

Open →

Product Page (NI)Product Page · ni.com

Open →

Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping

Free Shipping. Full policy terms apply.

Warranty

30-Day Warranty. Standard coverage applies.

Returns

30-Day Returns. Return policy applies.

Price / Availability

Contact SOHO ProLab for current quote and availability.

Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Explore equipment

Electronic Test and Instrumentation

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

What are the SWB-2815 part numbers?

The listed NI part numbers are 781420-15 and 781421-15.

How many rows, columns, and crosspoints does the SWB-2815 have?

It has 4 rows, 86 columns, and 344 crosspoints, with 1-wire routing.

What relay type does the SWB-2815 use?

The module uses reed relays.

What are the DC switching limits?

The maximum DC switching current is 0.25 A, and the maximum DC switching voltage is 100 V. Consult the NI specifications for operating conditions and additional limits.

Does the 0.3 A product descriptor mean 0.3 A DC switching current?

No. The preserved specifications list 0.25 A as the maximum DC switching current and 0.3 A as the maximum AC carry current. Switching current and carry current are distinct ratings.
