National Instruments SWB-2813 Matrix Module for SwitchBlock
1 image: Click to enlarge
National Instruments · NI SwitchBlock

SWB-2813

The NI SWB-2813 is a 2-wire, 4×21 reed-relay matrix card for NI SwitchBlock. It requires a SwitchBlock PXI carrier rather than installing directly as a standalone PXI module.

ManufacturerNational Instruments
ModelSWB-2813
Product TypeMatrix Module for SwitchBlock
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: SWB-2813

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Topology2-wire, 4 rows × 21 columns
Relay technologyReed
Maximum voltage150 V
Maximum switching current1 A
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

This matrix card forms part of a carrier-based PXI switching system. The PXI-2800 provides the SwitchBlock carrier interface and integrated analog bus.

Confirm the installed A/B configuration before planning row connections: Type A cards expose the analog bus at the front connector; Type B cards expose columns only.

  • Two-wire matrix signal switching.
  • Occupies one relay-card slot within the SwitchBlock carrier.
  • Listed as supported hardware in NI-SWITCH 21.3.
Verified specifications

Technical data

Verified product specifications.

Wire mode2-wire
Rows4
Columns21
Maximum voltage150 V
Maximum switching current1 A
Maximum carry current1 A
Maximum switching power20 W
Relay typeReed
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

PXI-2800 SwitchBlock carrier

Carrier for operation in a PXI chassis

SWB-2813

Matrix relay card

Compatibility

NI lists SH96F-96M and SH96F-96M-RES cables and the TBX-2809 remote terminal block for the 281x group, including SWB-2813. Review the guide's limitations before selecting accessories.

Confirm the A/B card configuration and required analog-bus access before selecting connections.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

SWB-2813 Dimensional DrawingsDimensional Drawings And CAD Models · ni.com
Open →
NI SwitchBlock Hardware ArchitectureTechnical Guide · ni.com
Open →
SwitchBlock Cable and Accessory CompatibilityCompatibility Guide · ni.com
Open →
Programming NI SwitchBlock in NI-SWITCH and NI-DAQmxTechnical resource
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Related products

Alternatives & system components

Related model
SWB-2814View product →
Related model
SWB-2833View product →

Explore equipment

Electronic Test and Instrumentation

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Can the SWB-2813 operate directly in a PXI chassis?

No. It requires the PXI Carrier Module for SwitchBlock; it is not a standalone PXI module.

Can it share analog bus lines with a 1-wire SWB-2816?

NI-SWITCH and NI-DAQmx do not allow analog-bus sharing between these different wire modes. NI documents lower-level relay control separately, which bypasses automatic software settings.
