National Instruments SWB-2814 Reed relay matrix module

1 image: Click to enlarge

National Instruments · NI SwitchBlock

SWB-2814

The National Instruments SWB-2814 is a 2-wire, 8×9 reed relay matrix module for NI SwitchBlock. It requires a SwitchBlock PXI carrier rather than installing directly as a standalone PXI module.

ManufacturerNational Instruments

ModelSWB-2814

Product TypeReed relay matrix module

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: SWB-2814

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Topology2-wire, 8 rows × 9 columns

Relay technologyReed

Maximum voltage150 V

Maximum switching current1 A

Carrier requirementPXI-2800 SwitchBlock carrier

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

The SWB-2814 provides an 8×9 matrix with two conductors switched per connection. NI documents the topology for both NI 2814A and NI 2814B variants, including channel naming and variant-dependent pin assignments.

The module belongs to the 281x SwitchBlock family. PXI system integration is through the SwitchBlock carrier; the relay card is not a standalone PXI instrument.

Two-wire matrix routing across eight rows and nine columns.
Reed relay switching with a maximum switching power of 20 W.
Occupies one relay-card slot in the SwitchBlock carrier.

Verified specifications

Technical data

Verified product specifications.

Switching mode	2-wire
Rows	8
Columns	9
Relay type	Reed
Maximum voltage	150 V
Maximum switching current	1 A
Maximum carry current	1 A
Maximum switching power	20 W
Relay-card slots used	1

Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

PXI-2800 SwitchBlock carrier

Carrier for PXI system integration

SWB-2814

2-wire 8×9 matrix relay card

Software identity

May appear as NI 2814A or NI 2814B in NI MAX and NI-SWITCH.

Confirm the A/B variant and its pinout before selecting wiring or planning row access.

Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI 2814 2-Wire 8×9 Matrix TopologyTopology And Pinout · ni.com

Open →

NI SwitchBlock Hardware ArchitectureTechnical Overview · ni.com

Open →

SwitchBlock Modules: Cable and Accessory CompatibilityCompatibility Guide · ni.com

Open →

Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping

Free Shipping. Full policy terms apply.

Warranty

30-Day Warranty. Standard coverage applies.

Returns

30-Day Returns. Return policy applies.

Price / Availability

Contact SOHO ProLab for current quote and availability.

Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Alternatives & system components

Explore equipment

Electronic Test and Instrumentation

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Can the SWB-2814 install directly into a PXI chassis?

No. It requires the PXI Carrier Module for SwitchBlock, identified as PXI-2800 in NI's compatibility guide.

What matrix topology does the SWB-2814 provide?

It provides a 2-wire matrix with eight rows and nine columns. NI's topology documentation covers both the NI 2814A and NI 2814B.

Does this record identify the A or B variant?

No. The catalog identifies SWB-2814 without an A/B suffix or manufacturer part number. Confirm the module label and use the corresponding NI pinout before wiring.
