National Instruments PXI-7851R Multifunction Reconfigurable I/O Module
1 image: Click to enlarge
National Instruments · PXI

PXI-7851R

The National Instruments PXI-7851R is an R Series PXI multifunction reconfigurable I/O module combining a Virtex-5 LX30 FPGA with 8 analog inputs, 8 analog outputs and 96 digital I/O lines.

ManufacturerNational Instruments
ModelPXI-7851R
Part Number780339-01
Product TypeMultifunction Reconfigurable I/O Module
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: PXI-7851R

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
FPGAVirtex-5 LX30
Analog inputs8 channels, 16-bit, up to 750 kS/s per channel
Analog outputs8 channels, 16-bit, up to 1 MS/s per channel
Analog ranges±10 V input and output
Digital I/O96 configurable lines
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The PXI-7851R provides FPGA-based onboard processing and direct control of I/O timing and synchronization. Its dedicated ADC on each analog input supports independent timing and triggering, including multirate acquisition.

The LabVIEW FPGA Module supports customization for hardware-in-the-loop testing, sensor simulation, custom protocol communication and high-speed control.

  • Analog input channels can sample simultaneously or at different rates.
  • Software-selectable differential, referenced single-ended and nonreferenced single-ended analog input modes; the selected mode applies to all input channels.
  • Digital lines support FPGA-defined inputs, outputs, counters or custom logic.
  • PXI timing can use an onboard clock phase-locked to the PXI 10 MHz reference.
Verified specifications

Technical data

Verified product specifications.

Analog input channels8 channels
Analog input resolution16 bits
Maximum analog input sampling rate750 per channel kS/s
Analog input range±10 V
Analog output channels8 channels
Analog output resolution16 bits
Maximum analog output update rate1 per channel MS/s
Analog output range±10 V
Bidirectional digital I/O96 lines
FPGAVirtex-5 LX30
FPGA flip-flops19200
FPGA 6-input LUTs19200
DSP48 slices32
Embedded FPGA block RAM1152 kbits
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

PXI

Hardware platform

PXI-7851R

R Series multifunction reconfigurable I/O module

FPGA development

Creating new FPGA VIs requires the LabVIEW FPGA Module.

Use the model-specific NI cable and accessory guide when selecting connections for mixed I/O and digital connectors.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI PXI-7851 Product PageProduct Page · ni.com
Open →
Multifunction Reconfigurable I/O SpecificationsSpecifications · docs-be.ni.com
Open →
Multifunction Reconfigurable I/O User ManualUser Manual · docs-be.ni.com
Open →
NI 78xx R Series Cable and Accessory CompatibilityTechnical resource
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Related products

Alternatives & system components

Related model
PXI-7852RView product →
Related model
PXI-7854RView product →

Explore equipment

PXI Platform

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Can the analog input channels run at different sampling rates?

Yes. The analog input channels support simultaneous sampling or sampling at different rates.

Which FPGA is fitted to the PXI-7851R?

The module uses a Virtex-5 LX30 FPGA.

Is LabVIEW alone sufficient to create new FPGA VIs?

No. Creating new FPGA VIs requires the LabVIEW FPGA Module. LabVIEW without that module can control existing FPGA VIs from a host application.
