The NI PCIe-7822 is an R Series digital I/O device with 128 channels, a Kintex-7 325T FPGA and 512 MB DRAM.
Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.
Key product information and technical features.
LabVIEW FPGA programming lets engineers define custom measurement hardware circuitry on the onboard reconfigurable FPGA. NI groups the PCIe-7822 with its digital reconfigurable I/O devices.
Verified product specifications.
| Maximum digital I/O frequency | 80 MHz |
|---|---|
| I/O connectors | 4 × 68-pin VHDCI |
| Channels per connector | 32 channels |
| Digital logic levels | 1.2, 1.5, 1.8, 2.5, 3.3 V |
| Logic-level configuration | Per connector; defined at compilation, not runtime |
| Digital signaling compatibility | LVTTL, LVCMOS |
| DMA channels | 16 |
Confirm condition, included accessories and revision before ordering.
Confirmed per unit.
Device / accessories confirmed in quote.
Exact revision confirmed when relevant.
Review system components and compatibility requirements.
Manufacturer
Host interface
R Series digital reconfigurable I/O device
LabVIEW FPGA Module
Manuals, software and technical resources for this model.
Review shipping, warranty and return terms before ordering.
Choose pricing, rental or repair for this exact model.
Product-specific answers based on available technical information.
The x4 PCI Express device supports x4, x8 and x16 PCI Express slots.
In a LabVIEW project, right-click the FPGA target and select Change I/O Configuration. Select the digital connectors and choose the required Logic Family.
NI lists the SHC68-C68-RDIO2 cable and SCB-68 HSDIO connector block for digital connections.
