The NI PCIe-7821 is an R Series PCI Express digital I/O device with 128 DIO, a Kintex-7 160T FPGA and 512 MB DRAM.
Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.
Key product information and technical features.
The PCIe-7821 belongs to NI's FPGA-based R Series. Its digital channels support reading and writing through FPGA I/O Nodes.
NI organizes the digital lines into four ports on each of four connectors. Each port contains eight lines, with the lowest-numbered line serving as the least significant bit.
Verified product specifications.
| Host interface | PCI Express |
|---|---|
| Digital I/O channels | 128 channels |
| FPGA | Kintex-7 160T |
| DRAM | 512 MB |
| Digital port width | 8 lines |
Confirm condition, included accessories and revision before ordering.
Confirmed per unit.
Device / accessories confirmed in quote.
Exact revision confirmed when relevant.
Review system components and compatibility requirements.
Manufacturer
Platform and product family
Digital reconfigurable I/O device
R Series FPGA programming uses the LabVIEW FPGA Module.
Manuals, software and technical resources for this model.
Review shipping, warranty and return terms before ordering.
Choose pricing, rental or repair for this exact model.
Product-specific answers based on available technical information.
Connectors 0–3 each expose four 8-line ports. DIOPORT 0 covers lines 0–7, DIOPORT 1 covers 8–15, DIOPORT 2 covers 16–23, and DIOPORT 3 covers 24–31.
No. NI requires digital outputs to be written either as ports or as lines, rather than mixing both configurations.
NI lists the SHC68-C68-RDIO2 cable and SCB-68 HSDIO connector block.
