NI (National Instruments) PCIe-7820 Kintex 7 160T FPGA Digital Reconfigurable I/O Device
1 image: Click to enlarge
NI (National Instruments) · Computer-Based Device

PCIe-7820

The NI PCIe-7820 is a PCI Express reconfigurable digital I/O device with a Kintex-7 160T FPGA and 128 bidirectional digital channels.

ManufacturerNI (National Instruments)
ModelPCIe-7820
Part Number785361-01
Product TypeKintex 7 160T FPGA Digital Reconfigurable I/O Device
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: PCIe-7820

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Bus ConnectorPCI Express
FPGAKintex-7 160T
Bidirectional Digital Channels128
External Clock Inputs4
Maximum Clock Rate80 MHz
Digital I/O Logic Levels1.2 V, 1.5 V, 1.8 V, 2.5 V, 3.3 V
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The PCIe-7820 brings FPGA-based digital I/O to a computer-based PCI Express system. Its user-programmable FPGA supports onboard processing and hardware-timed operation rather than relying solely on host software for digital control.

With LabVIEW FPGA, the digital lines can be configured for inputs, outputs, counter/timers, PWM, encoder inputs, or specialized communication protocols. The device uses VHDCI front connections and single-ended signaling with selectable digital logic levels.

  • User-programmable Kintex-7 160T FPGA for reconfigurable digital operation.
  • 128 bidirectional digital channels and four external clock inputs.
  • Maximum clock, acquisition, and generation rates of 80 MHz.
  • Selectable digital logic levels of 1.2 V, 1.5 V, 1.8 V, 2.5 V, and 3.3 V.
  • Supports custom onboard decision-making with hardware-timed operation.
  • Specified operating temperature range of 0 °C to 55 °C.
Verified specifications

Technical data

Verified product specifications.

Bus ConnectorPCI Express
FPGAKintex-7 160T
Number of Bidirectional Digital Channels128
Number of External Clock Inputs4
Maximum Clock Rate80 MHz
Digital I/O Logic Levels1.2 V, 1.5 V, 1.8 V, 2.5 V, 3.3 V
Dynamic RAM (DRAM)0 MB
ReconfigurableYes
Maximum Digital Update Rate80 ms
Operating Temperature Range0 °C to 55 °C
Bus ConnectionPCI Express
Front Connection TypeVHDCI
Signaling TypeSingle-Ended
Supported Hardware PlatformComputer-Based Device
Digital I/O Termination50 Ohm
Output Voltage Range0 V to 3.3 V
Maximum Acquisition Rate80 MHz
Maximum Generation Rate80 MHz
Maximum Data Rate80 MHz
Supports Hardware CompareNo
NI part numbers785361-01
