National Instruments PCI-6035E Multifunction data acquisition card
1 image: Click to enlarge
National Instruments · PCI

PCI-6035E

The National Instruments PCI-6035E is a PCI multifunction DAQ card with 16-bit analog input at up to 200 kS/s. It combines analog I/O, eight digital I/O lines, and two counter/timers.

ManufacturerNational Instruments
ModelPCI-6035E
Part Number778026-01
Product TypeMultifunction data acquisition card
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: PCI-6035E

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Analog inputs16 single-ended or 8 differential
Input performance16-bit; up to 200 kS/s
Analog outputs2 channels, 12-bit
Digital I/O8 lines
Counters2 × 24-bit
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The PCI-6035E combines voltage acquisition, voltage output, digital I/O, and counter/timer functions on a PCI card. NI identifies laboratory automation, research, design verification, and manufacturing test as relevant applications.

Its analog input and output resolutions differ: input conversion is 16-bit, while the two analog outputs are 12-bit. This distinction is important when comparing it with the PCI-6036E.

  • Software-selectable single-ended or differential analog inputs.
  • Four bipolar analog input ranges.
  • Analog and digital I/O with two counter/timers on one PCI device.
Verified specifications

Technical data

Verified product specifications.

Analog input configuration16 single-ended or 8 differential
Analog input resolution16 bit
Maximum analog input sampling rate200 kS/s
Analog input ranges±10 V, ±5 V, ±500 mV, ±50 mV
Analog output channels2
Analog output resolution12 bit
Analog output range±10 V
Maximum analog output update rate10 via DMA; system-dependent kHz
Digital I/O8 lines; 5 V TTL/CMOS
Counter/timers2 × 24-bit
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

PCI

Host interface

PCI-6035E

Multifunction DAQ card

Historical driver evidence

NI-DAQmx 8.3 lists PCI-6035E among supported devices.

Verify the intended driver release and operating system before integration; historical support does not establish support in current releases.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI 6034E/6035E/6036E Family SpecificationsSpecifications And Pinouts · download.ni.com
Open →
NI PCI-6035 Product PageOfficial Product Page · ni.com
Open →
NI-DAQmx 8.3 ReadmeHistorical Driver Compatibility · download.ni.com
Open →
Electrical specifications and family pinout drawingsTechnical resource
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Related products

Alternatives & system components

Related model
PCI-6034EView product →
Related model
PCI-6036EView product →

Explore equipment

Electronic Test and Instrumentation

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Are the PCI-6035E analog outputs 16-bit?

No. Its analog inputs are 16-bit, but its two analog outputs are 12-bit.

How many differential inputs does it provide?

It supports eight differential inputs or sixteen single-ended inputs.

Why does NI's product page say PCI-6035 rather than PCI-6035E?

NI titles the page PCI-6035, but its part-number description explicitly identifies PCI-6035E and associates it with 778026-01.
