National Instruments USB-6259 Screw Terminal Multifunction data acquisition device
1 image: Click to enlarge
National Instruments · USB

NI USB-6259 Screw Terminal

The NI USB-6259 Screw Terminal is an M Series multifunction USB DAQ device with 32 analog inputs, four analog outputs, 48 digital I/O lines and two 32-bit counters. Integrated screw terminals provide direct signal wiring.

ManufacturerNational Instruments
ModelUSB-6259 Screw Terminal
Product TypeMultifunction data acquisition device
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: USB-6259 Screw Terminal

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Analog inputs32 single-ended or 16 differential; 16-bit
Input sampling1.25 MS/s single-channel; 1 MS/s aggregate multichannel
Analog outputs4 channels, 16-bit
Digital I/O48 lines; 32 hardware-timed
CountersTwo 32-bit counters/timers
Signal connectionIntegrated screw terminals
