National Instruments NI 9205 C Series voltage input module
1 image: Click to enlarge
National Instruments · CompactDAQ and CompactRIO

NI 9205

The NI 9205 is a C Series voltage input module with 32 single-ended or 16 differential inputs and 16-bit resolution. Its multiplexed acquisition architecture provides up to 250 kS/s aggregate sampling.

ManufacturerNational Instruments
ModelNI 9205
Part Number779519-01
Product TypeC Series voltage input module
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: NI 9205

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Input configuration32 single-ended or 16 differential inputs
Resolution16-bit
Maximum sample rate250 kS/s aggregate, shared across active channels
Input ranges±0.2 V, ±1 V, ±5 V and ±10 V
