National Instruments NI 9201 C Series voltage input module
1 image: Click to enlarge
National Instruments · CompactDAQ and CompactRIO

NI 9201

The NI 9201 is an eight-channel, single-ended C Series voltage input module with a ±10 V input range, 12-bit resolution and 500 kS/s aggregate scanning rate. It is designed for CompactDAQ and CompactRIO systems.

ManufacturerNational Instruments
ModelNI 9201
Part Number779013-01
Product TypeC Series voltage input module
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: NI 9201

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Inputs8 single-ended voltage channels
Input range±10 V
Resolution12 bits
Scanning rate500 kS/s aggregate; not per channel
Operating temperature-40 °C to 70 °C
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The NI 9201 adds multiplexed voltage acquisition to an NI C Series system. Its eight single-ended inputs share the conversion hardware rather than sampling all channels simultaneously.

NI offers screw-terminal, spring-terminal and DSUB versions. The catalog-associated part number 779013-01 identifies the screw-terminal version; confirm the module label and connector before selecting wiring accessories.

  • Bipolar ±10 V measurement range across eight single-ended inputs.
  • 12-bit successive approximation register (SAR) conversion.
  • 500 kS/s aggregate scanning for multichannel voltage acquisition.
  • C Series module format for CompactDAQ and CompactRIO systems.
Verified specifications

Technical data

Verified product specifications.

Analog input channels8 single-ended
Nominal input range-10 to +10 V
ADC resolution12 bits
ADC typeSuccessive approximation register (SAR)
Maximum scanning sample rate500 aggregate; 475 in R Series expansion chassis kS/s
Simultaneous samplingNo
Operating temperature-40 to +70 °C
Maximum active power consumption from chassis1 W
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

CompactDAQ / CompactRIO

Host system platforms

C Series

Modular I/O interface and family

NI 9201

Voltage input module

Confirm the exact chassis, software support and connector variant before integration. The 500 kS/s scanning rate is shared across active channels.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI-9201 Official Product PageProduct Page · ni.com
Open →
NI-9201 and sbRIO-9201 SpecificationsSpecifications · ni.com
Open →
NI 9201 Getting Started GuideGetting Started Guide · download.ni.com
Open →
NI 9201 DatasheetDatasheet · download.ni.com
Open →
NI-9201 Dimensional Drawings and CAD ModelsTechnical resource
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Related products

Alternatives & system components

Related model
NI 9205View product →
Related model
NI 9215View product →

Explore equipment

CompactDAQ

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Is the NI 9201 a 16-channel, 14-bit module?

No. NI specifies eight single-ended analog input channels and 12-bit resolution.

Which connector does part number 779013-01 use?

NI identifies 779013-01 as the screw-terminal NI 9201 variant. Spring-terminal and DSUB versions have different part numbers.
