National Instruments NI 9215 C Series Voltage Input Module
1 image: Click to enlarge
National Instruments · CompactDAQ and CompactRIO

NI 9215

The NI 9215 is a four-channel differential voltage input module with a ±10 V input range, 16-bit resolution and simultaneous sampling up to 100 kS/s per channel. It is designed for NI CompactDAQ and CompactRIO systems.

ManufacturerNational Instruments
ModelNI 9215
Part Number779011-01
Product TypeC Series Voltage Input Module
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: NI 9215

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Analog inputs4 differential channels
Input range±10 V
Resolution16 bits
Maximum sampling rate100 kS/s per channel, simultaneous
Tagged part number779011-01 — screw-terminal variant
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The NI 9215 acquires four voltage signals simultaneously. Independent track-and-hold amplifiers allow all channels to be sampled together, rather than sequentially through a multiplexed input.

NI offers screw-terminal, spring-terminal and BNC versions. The catalog's tagged part number, 779011-01, corresponds to the screw-terminal version; connector-specific wiring and isolation limits must be checked before installation.

  • Simultaneous acquisition across four differential voltage inputs.
  • 16-bit successive approximation register ADC architecture.
  • Buffered and conditioned input signals with independent track-and-hold amplifiers.
  • Channel-to-earth isolation; isolation ratings depend on the connector variant.
Verified specifications

Technical data

Verified product specifications.

Analog input channels4 channels
Input configurationDifferential
Nominal input range±10.0 V
ADC resolution16 bits
Maximum sample rate per channel100 kS/s
Sampling methodSimultaneous
ADC typeSuccessive approximation register (SAR)
Overvoltage protection±30 V
Four-channel conversion time10 µs
Channel-to-channel isolationNone
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

CompactDAQ / CompactRIO

Host system platforms

NI 9215

C Series simultaneous voltage input module

Measurement function

Four-channel differential voltage acquisition

Confirm the installed connector variant and its safety limits. Channel-to-earth isolation does not provide channel-to-channel isolation.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI-9215 Official Product PageProduct Page · ni.com
Open →
NI-9215 and sbRIO-9215 SpecificationsSpecifications · ni.com
Open →
NI 9215 DatasheetPDF Datasheet · download.ni.com
Open →
NI-9215 Dimensional DrawingsDimensional Drawings And CAD Models · ni.com
Open →
NI-9215 Mechanical Drawings and CAD DownloadsTechnical resource
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Related products

Alternatives & system components

Related model
NI 9205View product →
Related model
NI 9206View product →

Explore equipment

CompactDAQ

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Is the NI 9215 a thermocouple input module?

No. NI identifies the NI 9215 as a four-channel C Series voltage input module with a ±10 V range, not a dedicated thermocouple input module.

Does the NI 9215 sample all four channels simultaneously?

Yes. It supports simultaneous sampling at up to 100 kS/s per channel.

Which connector corresponds to part number 779011-01?

NI identifies 779011-01 as the screw-terminal version. Confirm the physical module label and connector before selecting wiring accessories.

Are the input channels isolated from each other?

No. The specifications state that there is no channel-to-channel isolation. Channel-to-earth isolation ratings are connector-dependent.
