National Instruments · USRP

USRP-2950

The NI USRP-2950 is a reconfigurable software defined radio covering 50 MHz to 2.2 GHz, with two transmit and two receive channels. Its GPS-disciplined 10 MHz OCXO reference supports frequency accuracy and synchronization in wireless research systems.

ManufacturerNational Instruments

ModelUSRP-2950

Product TypeReconfigurable software defined radio

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: USRP-2950

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

RF frequency range50 MHz to 2.2 GHz

RF channels2 transmit / 2 receive

Reference clockGPS-disciplined 10 MHz OCXO

Bandwidth variants40 MHz and 120 MHz; exact unit variant requires confirmation

Host interfaces1/10 Gigabit Ethernet and PCI/MXI Express

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

The USRP-2950 combines reconfigurable radio hardware with a LabVIEW design workflow for prototyping wireless communication systems. NI identifies MIMO, spectrum sensing, cognitive radio, beamforming, and direction finding among its research applications.

NI documents both 40 MHz and 120 MHz USRP-2950 variants. The supplied catalog description identifies 40 MHz, but the model name alone does not distinguish the bandwidth option; verify the unit identification before selecting a configuration.

RF tuning coverage from 50 MHz to 2.2 GHz.
Two transmit channels and two receive channels.
GPS-disciplined oven-controlled reference oscillator for improved frequency accuracy and synchronization.
Reconfigurable architecture for LabVIEW-based wireless system prototyping.
Ethernet and PCI/MXI Express host connectivity documented in NI-USRP 2022 Q4.

Verified specifications

Technical data

Verified product specifications.

RF frequency range	50 MHz to 2.2 GHz
Transmit channels	2 channels
Receive channels	2 channels
Reference oscillator	GPS-disciplined OCXO
Reference clock frequency	10 MHz
Documented model bandwidth options	40 or 120 MHz
Host connectivity	1 GbE, 10 GbE, PCI/MXI Express

Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

USRP

Software defined radio platform

USRP-2950

GPS-disciplined reconfigurable RF transceiver

Driver evidence

NI-USRP 2022 Q4 explicitly lists both USRP-2950 bandwidth variants.

Confirm the bandwidth variant and host interface before selecting software, cables, or an FPGA workflow.

Manuals & software

Technical resources

Manuals, software and technical resources for this model.

USRP-2950 Product SupportOfficial Product Page · ni.com

Open →

NI USRP Software Defined RadiosProduct Brochure · ni.com

Open →

NI-USRP 2022 Q4 ReadmeDriver Compatibility And Interface Reference · ni.com

Open →

NI-USRP 2022 Q4: Supported Hardware and Ethernet GuidanceTechnical resource

Open →

Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping

Free Shipping. Full policy terms apply.

Warranty

30-Day Warranty. Standard coverage applies.

Returns

30-Day Returns. Return policy applies.

Price / Availability

Contact SOHO ProLab for current quote and availability.

Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Alternatives & system components

Explore equipment

Wireless Design and Test

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

What RF range does the USRP-2950 cover?

The USRP-2950 covers 50 MHz to 2.2 GHz.

Does every USRP-2950 have 40 MHz bandwidth?

No. NI lists separate 40 MHz and 120 MHz variants. This catalog record lists 40 MHz, but its unit-specific bandwidth option still requires confirmation.

Does the USRP-2950 include a GPS-disciplined reference?

Yes. NI specifies a GPS-disciplined 10 MHz oven-controlled crystal oscillator reference clock.

Can the FPGA be modified through an Ethernet connection?

NI-USRP 2022 Q4 states that the FPGA cannot be modified when a USRP-294x/295x device is connected through Ethernet. Plan the host interface around the required FPGA workflow.
