National Instruments SWB-2811 Matrix Module for SwitchBlock

1 image: Click to enlarge

National Instruments · NI SwitchBlock

SWB-2811

The National Instruments SWB-2811 is an 8×21 reed-relay matrix card for NI SwitchBlock. It requires a SwitchBlock PXI carrier rather than operating as a standalone PXI module.

ManufacturerNational Instruments

ModelSWB-2811

Product TypeMatrix Module for SwitchBlock

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: SWB-2811

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Matrix8 rows × 21 columns

Relay technologyReed

Maximum voltage150 V

Maximum switching current1 A

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

The SWB-2811 fits into the modular SwitchBlock architecture, where relay cards can operate as individual matrices or be combined through the carrier analog bus.

NI identifies SwitchBlock modules in software with A or B suffixes. The catalog record does not establish which configuration this unit represents; confirm the physical label before planning signal access.

8×21 matrix topology.
Reed-relay switching with a 20 W maximum switching-power rating.
Listed as supported hardware in NI-SWITCH 2023 Q1.

Verified specifications

Technical data

Verified product specifications.

Number of rows	8
Number of columns	21
Relay type	Reed
Maximum voltage	150 V
Maximum switching current	1 A
Maximum carry current	1 A
Maximum switching power	20 W
Carrier relay-card slots used	1
Signal connector type	Custom

Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

PXI-2800

SwitchBlock PXI carrier

SWB-2811

Matrix relay card

Software

NI-SWITCH 2023 Q1 explicitly lists SWB-2811 support.

Confirm the A/B configuration and required carrier before integration.

Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI SwitchBlock Hardware ArchitectureArchitecture Guide · ni.com

SwitchBlock Modules: Switches Cable and Accessory CompatibilityCompatibility Guide · ni.com

NI-SWITCH 2023 Q1 ReadmeDriver Documentation · ni.com

Programming the NI SwitchBlock in NI-SWITCH and NI-DAQmxTechnical resource

Determining SwitchBlock Relay Drive LimitsTechnical resource
