PCI-CAN/XS2

The National Instruments PCI-CAN/XS2 is a two-port PCI CAN interface in the Series 2 family. It supports software selection of high-speed, low-speed/fault-tolerant, and single-wire CAN physical layers.

ManufacturerNational Instruments

ModelPCI-CAN/XS2

Part Number778782-02

Product TypeTwo-port software-selectable CAN interface

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: PCI-CAN/XS2

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Host platformPCI

CAN ports2

Physical layersSoftware-selectable high-speed, low-speed/fault-tolerant, and single-wire CAN

Connections9-pin D-sub

Hardware generationSeries 2

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

The PCI-CAN/XS2 combines two CAN ports with a PCI host interface. Its software-selectable physical layers distinguish it from the fixed high-speed PCI-CAN/2 and low-speed/fault-tolerant PCI-CAN/LS2 models.

NI lists the PCI-CAN/XS2 among the Series 2 devices supported by NI-CAN 18.5. Check the release-specific operating-system and development-environment requirements before selecting a software installation.

Two CAN ports on a PCI interface card.
Software-selectable high-speed, low-speed/fault-tolerant, and single-wire CAN support.
9-pin D-sub CAN connections.
Listed hardware support in NI-CAN 18.5.

Verified specifications

Technical data

Verified product specifications.

Host interface	PCI
CAN port count	2 ports
CAN physical layers	Software-selectable high-speed, low-speed/fault-tolerant, and single-wire
Connector type	9-pin D-sub
Hardware generation	Series 2
Manufacturer ordering part number	778782-02
