PCI-4462

The National Instruments PCI-4462 is a four-input PCI sound and vibration acquisition device with 24-bit conversion and sampling up to 204.8 kS/s. It provides AC/DC input coupling and has no analog output channels.

ManufacturerNational Instruments

ModelPCI-4462

Part Number779309-01

Product TypeSound and vibration data acquisition device

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: PCI-4462

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Host interfacePCI

Analog inputs4 simultaneous channels

Resolution24-bit

Maximum sample rate204.8 kS/s

Analog outputsNone

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

The PCI-4462 belongs to NI's dynamic signal acquisition family for sound and vibration measurements on PCI-based computers. Its input-only design provides four measurement channels rather than signal-generation outputs.

Each input supports independently selectable differential or pseudodifferential configuration and AC or DC coupling. Analog signals connect through female BNC connectors; the digital trigger uses a male SMB connector.

Simultaneous acquisition on four analog input channels.
24-bit dynamic signal acquisition.
AC/DC coupling with a 3.4 Hz AC-coupling cutoff.
Per-channel IEPE excitation selection: off, 4 mA, or 10 mA.

Verified specifications

Technical data

Verified product specifications.

Bus interface	PCI
Simultaneously sampled analog inputs	4 channels
ADC resolution	24 bits
Maximum sample rate	204.8 kS/s
Input configuration	Differential or pseudodifferential; independently software selectable
Input coupling	AC or DC
AC-coupling cutoff, -3 dB	3.4 Hz
Analog input connectors	BNC female
Digital trigger connector	SMB male
IEPE excitation current	0, 4, or 10; 4 and 10 mA settings have ±15% tolerance mA
