National Instruments NI-9435 Digital input module
1 image: Click to enlarge
National Instruments · CompactDAQ

NI-9435

The NI-9435 is a four-channel C Series digital input module for AC/DC signals with sinking or sourcing inputs. It provides detachable screw-terminal connections and an LED for each input channel.

ManufacturerNational Instruments
ModelNI-9435
Part Number779010-01
Product TypeDigital input module
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: NI-9435

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Digital inputs4 channels
Input directionSinking or sourcing
Signal range±5 to ±250 VDC; 10 to 250 VAC
Connection10-terminal detachable screw-terminal connector
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The NI-9435 connects industrial switches, transducers, and other discrete signal sources to a C Series measurement system. In a CompactDAQ chassis, it supports correlated digital operations, triggering, and synchronization.

Each channel uses a pair of interchangeable DIa and DIb terminals. The module detects the digital state from the voltage difference between these terminals rather than measuring an analog voltage value.

  • Accepts sinking-output and sourcing-output devices.
  • Supports both AC and DC discrete input signals.
  • Individual channel LEDs indicate input states.
  • Provides transient overvoltage protection between input channels and earth ground.
Verified specifications

Technical data

Verified product specifications.

Digital input channels4 channels
Input typeSinking or sourcing
DC signal range±5 to ±250 VDC
AC signal range10 to 250 VAC
Nominal update time3 ms
Maximum input delay time2.8 ms
Front connector10-terminal detachable screw-terminal connector
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

CompactDAQ / C Series

Chassis platform and module family

NI-9435

Four-channel digital input module

System integration

Supports correlated digital operations in CompactDAQ.

Check the exact chassis and software combination in NI's compatibility documentation before integration.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI-9435 Official Product PageProduct Page · ni.com
Open →
NI 9435 Operating Instructions and SpecificationsManual · download.ni.com
Open →
C Series Module and CompactDAQ or CompactRIO Hardware Compatibility with LabVIEWTechnical resource
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Related products

Alternatives & system components

Related model
NI-9437View product →
Related model
NI-9422View product →

Explore equipment

CompactDAQ

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Can the NI-9435 accept both AC and DC signals?

Yes. NI specifies signal ranges of ±5 to ±250 VDC and 10 to 250 VAC.

Is the NI-9435 a digital output module?

No. It provides four digital input channels for sensing discrete signal states.

What does the 3 ms rating describe?

NI lists a 3 ms update time for this module. The operating manual separately specifies a maximum input delay of 2.8 ms; these are distinct specification labels.
