NI 9219

The NI 9219 is a four-channel C Series universal analog input module with 24-bit simultaneous sampling and a maximum rate of 100 S/s per channel. It supports multiple sensor and electrical measurement types rather than thermocouples alone.

ManufacturerNational Instruments

ModelNI 9219

Part Number779781-01

Product TypeC Series universal analog input module

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: NI 9219

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Channels4 analog inputs

Resolution24-bit

Maximum sample rate100 S/s per channel

SamplingSimultaneous

Measurement flexibilityIndividually selectable measurement type on each channel

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

Designed for multipurpose testing, the NI 9219 measures thermocouples, RTDs, strain gages, load cells and powered sensors. Its independently configurable channels allow different measurement types within one module.

The module fits the NI C Series measurement ecosystem and is presented by NI as a CompactDAQ universal analog input option. Select the measurement mode and wiring for each sensor before configuring acquisition.

Built-in voltage and current excitation for supported sensor measurements.
Quarter-bridge, half-bridge and full-bridge measurement support.
Delta-sigma ADCs with analog prefiltering.
Selectable high-resolution, best 50 Hz rejection, best 60 Hz rejection and high-speed timing modes.

Verified specifications

Technical data

Verified product specifications.

Analog input channels	4 channels
ADC resolution	24 bits
Maximum sample rate	100 S/s/channel
Sampling mode	Simultaneous
Nominal voltage input ranges	±60 V, ±15 V, ±4 V, ±1 V, ±125 mV
Nominal current input range	±25 mA
Nominal thermocouple input range	±125 mV
Resistance measurement	2-wire and 4-wire; nominal 1 kΩ and 10 kΩ ranges
RTD measurement	3-wire and 4-wire; Pt 100 and Pt 1000

Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

CompactDAQ / C Series

Modular measurement platform

NI 9219

Universal analog input module

System planning

Check the NI hardware compatibility table for the intended chassis and software configuration.

Confirm the module label and exact chassis/software combination; model-level documentation does not establish the supplied unit's revision or accessories.
