NI-9216

The NI-9216 is an eight-channel C Series temperature input module for PT100 RTDs. This record identifies the non-conformal-coated D-Sub version, part number 783863-01.

ManufacturerNational Instruments

ModelNI-9216

Part Number783863-01

Product TypeRTD temperature input module

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: NI-9216

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Inputs8 PT100 RTD channels

Maximum sampling400 S/s aggregate; 50 S/s/channel

Resolution24-bit

RTD wiring3-wire and 4-wire with automatic detection

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

The NI-9216 provides RTD temperature acquisition within a CompactDAQ system. NI lists it as a general-purpose PT100 temperature measurement option in its CompactDAQ system build guide.

Selectable high-speed and high-resolution modes balance acquisition speed against measurement noise. Channels share an isolated common ground; they are not individually isolated.

Automatic detection of 3-wire or 4-wire RTD connections.
Built-in 1 mA excitation per channel.
50/60 Hz normal-mode noise rejection in high-resolution mode.

Verified specifications

Technical data

Verified product specifications.

Analog input channels	8 channels
Maximum aggregate sample rate	400 S/s
ADC resolution	24 bits
Resistance measurement range	0 to 400 Ω
Temperature measurement range	-200 to 850 °C
Sampling mode	Scanned
Front connection	D-Sub
Conformal coating	No
Continuous channel-to-earth isolation, D-Sub	60 VDC, Measurement Category I
Channel-to-channel isolation	None
Typical temperature accuracy example	±0.15 °C at 25 °C ambient, -200 to 150 °C measured temperature, 4-wire high-resolution mode; add 0.1 °C in high-speed mode
Operating temperature	-40 to 70 °C
