National Instruments NI 9214 Thermocouple temperature input module
1 image: Click to enlarge
National Instruments · CompactDAQ and CompactRIO

NI 9214

The NI 9214 is a 16-channel C Series thermocouple input module for CompactDAQ and CompactRIO. Its TB-9214 isothermal terminal block supports cold-junction compensation.

ManufacturerNational Instruments
ModelNI 9214
Part Number781510-01
Product TypeThermocouple temperature input module
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: NI 9214

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Inputs16 thermocouple channels
Resolution24-bit
Input range±78.125 mV
Terminal connectionTB-9214 screw terminals
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

Designed for higher-channel-count temperature systems, the NI 9214 uses an autozero channel to compensate for offset error. The terminal-block layout minimizes thermal gradients.

Acquisition is scanned, not simultaneous. High-resolution and high-speed modes trade noise performance against acquisition speed.

  • TB-9214 incorporates three internal cold-junction compensation channels.
  • High-resolution mode rejects power-line noise.
  • Open-thermocouple detection circuitry identifies disconnected sensors.
Verified specifications

Technical data

Verified product specifications.

Thermocouple input channels16 channels
ADC resolution24 bits
ADC typeDelta-sigma
Sampling modeScanned
Voltage measurement range±78.125 mV
High-speed sample rate, all channels68; includes autozero and cold-junction compensation channels S/s
High-resolution sample rate, all channels0.96; includes autozero and cold-junction compensation channels S/s
Supported thermocouple typesJ, K, T, E, N, B, R, S
Operating temperature-40 to 70 °C
Channel-to-earth isolation250 Vrms
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

C Series

Modular I/O family

NI 9214

Thermocouple input module

System platforms

CompactDAQ and CompactRIO

Confirm the physical module label and TB-9214 presence before system integration; the catalog tag contains a conflicting part number.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI-9214 Official Product PageProduct Page · ni.com
Open →
NI 9214 and TB-9214 DatasheetDatasheet · download.ni.com
Open →
Accuracy of NI 9214 Expressed in V and °CTechnical resource
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Related products

Alternatives & system components

Related model
NI 9211View product →
Related model
NI 9213View product →

Explore equipment

CompactDAQ

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Is the NI 9214 a general-purpose ±10 V input module?

No. It is a thermocouple temperature input module with a ±78.125 mV measurement range.

Does the NI 9214 sample channels simultaneously?

No. It uses scanned acquisition through a shared ADC.

Which terminal block does it use?

It uses the TB-9214, which NI identifies as exclusively compatible with the NI-9214. Accessory inclusion for this catalog item has not been established.
