NI 9211

The NI 9211 is a four-channel C Series temperature input module with ±80 mV inputs and 24-bit resolution. It provides thermocouple signal conditioning with cold-junction compensation and open-thermocouple detection.

ManufacturerNational Instruments

ModelNI 9211

Part Number779001-01

Product TypeThermocouple temperature input module

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: NI 9211

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Inputs4 differential channels

Resolution24-bit

Input range±80 mV

Acquisition14 S/s aggregate; scanned

ConnectionScrew terminals

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

The NI 9211 fits CompactDAQ and CompactRIO chassis as a C Series thermocouple module. Its acquisition is scanned rather than simultaneous.

Cold-junction compensation for thermocouple measurements.
Open-thermocouple detection.
Anti-aliasing filters.
50 Hz and 60 Hz noise rejection.

Verified specifications

Technical data

Verified product specifications.

Thermocouple input channels	4 channels
ADC resolution	24 bits
ADC type	Delta-sigma
Sampling mode	Scanned
Voltage measurement range	±80 mV
Aggregate sampling rate	14 S/s
Conversion time	70 per channel; 420 for all channels including internal autozero and cold-junction channels ms
Supported thermocouple types	J, K, T, E, N, B, R, S
Channel-to-earth isolation	250 continuous, Measurement Category II Vrms
Channel-to-channel isolation	None
Operating temperature	-40 to 70 °C
