National Instruments 9208 Measurement System C Series Current Input Module

1 image: Click to enlarge

National Instruments · CompactDAQ / CompactRIO

NI 9208 Measurement System

The NI 9208 is a 16-channel, 24-bit C Series current input module for industrial measurement systems. It supports scanned acquisition with high-speed and high-resolution operating modes.

ManufacturerNational Instruments

Model9208 Measurement System

Part Number780968-01

Product TypeC Series Current Input Module

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: 9208 Measurement System

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Measurement typeAnalog current input

Channels16

ADC resolution24-bit

Nominal current range±20 mA

Sampling architectureScanned, not simultaneous

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

High-resolution mode provides 50/60 Hz rejection for low-frequency noise reduction. For faster acquisition, high-speed mode uses a 2 ms conversion time per channel; channels are scanned rather than sampled simultaneously.

16 analog current input channels in a C Series module.
24-bit delta-sigma analog-to-digital conversion.
Selectable high-speed and high-resolution conversion modes.
High-resolution mode includes 50/60 Hz noise rejection.

Verified specifications

Technical data

Verified product specifications.

Analog input channels	16 channels
ADC resolution	24 bits
ADC type	Delta-sigma
Sampling mode	Scanned
Input range	±21.5 minimum; ±22 typical mA
High-speed conversion time	2 per channel ms
High-resolution conversion time	52 per channel ms
Input impedance	85 Ω
Operating temperature	-40 to 70 °C

Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

CompactDAQ / CompactRIO

Supported system platforms; verify chassis and software configuration

NI 9208

C Series current input module

Catalog part-number reference

780968-01 identifies the D-SUB version in NI's product table.

Confirm the module part number and connector before selecting wiring accessories or applying connector-specific safety limits.

Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI-9208 Product PageProduct Page · ni.com

Open →

NI-9208 SpecificationsSpecifications · ni.com

Open →

NI 9208 Getting Started GuideGetting Started Guide · download.ni.com

Open →

NI-9208 Dimensional DrawingsDimensional Drawings And CAD Models · ni.com

Open →

C Series Module and CompactDAQ or CompactRIO Hardware CompatibilityTechnical resource

Open →

Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping

Free Shipping. Full policy terms apply.

Warranty

30-Day Warranty. Standard coverage applies.

Returns

30-Day Returns. Return policy applies.

Price / Availability

Contact SOHO ProLab for current quote and availability.

Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Alternatives & system components

Explore equipment

CompactDAQ

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Is the NI 9208 an analog output module?

No. NI identifies it as a 16-channel C Series current input module with 24-bit resolution.

Does the NI 9208 sample all channels simultaneously?

No. It uses scanned acquisition. Conversion time is 2 ms per channel in high-speed mode and 52 ms per channel in high-resolution mode.

Which connector corresponds to part number 780968-01?

NI lists 780968-01 as the D-SUB current input module. Verify the physical module label because the NI 9208 family also includes a spring-terminal version.
