The NI cFP-TC-125 provides eight thermocouple inputs for Compact FieldPoint systems.
Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.
Key product information and technical features.
NI identifies the cFP-TC-125 as an eight-channel thermocouple module in its Compact FieldPoint migration guide. It is distinct from the cFP-TC-120, which is listed separately.
NI strongly recommends the cFP-CB-3 for thermocouple measurements. Its isothermal construction minimizes thermal gradients at the terminals, supporting improved measurement accuracy.
Verified product specifications.
| Channel count | 8 channels |
|---|---|
| ADC resolution | 16 bits |
| ADC architecture | Delta-sigma |
| Voltage input range | -20 to 80 mV |
| Operating temperature | -40 to 70 °C |
Confirm condition, included accessories and revision before ordering.
Confirmed per unit.
Device / accessories confirmed in quote.
Exact revision confirmed when relevant.
Review system components and compatibility requirements.
Manufacturer
Modular I/O platform
Thermocouple input module
Mounts on a cFP-BP-x or cFP-180x backplane.
Manuals, software and technical resources for this model.
Review shipping, warranty and return terms before ordering.
Choose pricing, rental or repair for this exact model.
Product-specific answers based on available technical information.
NI recommends the cFP-CB-3 isothermal connector block for cFP-TC-125 thermocouple measurements to reduce terminal thermal gradients.
Yes. Its voltage input range is -20 to 80 mV.
No. Measurement error depends on thermocouple type, measured temperature, cold-junction temperature and sensor accuracy.
