USRP-2945
1 image: Click to enlarge
NI (National Instruments) · Ethernet, MXI Express

USRP-2945

The NI USRP-2945 is a reconfigurable software-defined radio device with four receiver channels, a 10 MHz to 6 GHz RF frequency range, and 80 MHz instantaneous input bandwidth.

ManufacturerNI (National Instruments)
ModelUSRP-2945
Part Number785263-01
Product Type10 MHz to 6 GHz, 80 MHz Bandwidth, Reconfigurable USRP Software Defined Radio Device
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: USRP-2945

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Bus ConnectionEthernet, MXI Express
RF Frequency Range10 MHz to 6 GHz
RF Transceiver Instantaneous Input Bandwidth80 MHz
Number of Input Channels4
GPSDONo
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The USRP-2945 provides an integrated hardware and software solution for prototyping wireless receiver systems and acquiring over-the-air signals for analysis. It is a receive-only device with four input channels and no output channels.

Its two-stage superheterodyne architecture uses four independent receiver channels and shared local oscillators for phase-coherent operation. The Kintex-7 410T FPGA is programmable with the LabVIEW FPGA Module.

  • RF frequency coverage from 10 MHz to 6 GHz.
  • Four receiver inputs with 80 MHz instantaneous input bandwidth.
  • Reconfigurable Kintex-7 410T FPGA.
  • Ethernet and MXI Express bus connections.
  • Supports peer-to-peer streaming.
  • Shared local oscillators support phase-coherent receiver operation.
Verified specifications

Technical data

Verified product specifications.

Bus ConnectionEthernet, MXI Express
RF Frequency Range10 MHz to 6 GHz
GPSDONo
RF Transceiver Instantaneous Input Bandwidth80 MHz
Number of Input Channels4
FPGAKintex-7 410T
ReconfigurableYes
Supports Peer To Peer StreamingYes
NI part numbers785263-01
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

NI

Manufacturer

Ethernet, MXI Express

Bus Connection

USRP-2945

This product

Platform shown as listed by NI. Confirm controller, chassis and software fit for your system with NI before integration.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

Letter Of Volatility (NI)Letter Of Volatility · ni.com
Open →
Specifications (NI)Specifications · ni.com
Open →
Getting Started (NI)Getting Started · ni.com
Open →
Dimensional Drawings (NI)Dimensional Drawings · ni.com
Open →
Product Page (NI)Product Page · ni.com
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Explore equipment

Wireless Design and Test

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Can the USRP-2945 transmit RF signals?

No. The USRP-2945 has four receiver input channels and zero output channels.

What frequency range and bandwidth does it support?

Its RF frequency range is 10 MHz to 6 GHz, with 80 MHz instantaneous input bandwidth.

Is the FPGA reconfigurable?

Yes. The USRP-2945 uses a reconfigurable Kintex-7 410T FPGA that is programmable with the LabVIEW FPGA Module.

Does the USRP-2945 include a GPSDO?

No. The USRP-2945 configuration listed here does not include a GPS-disciplined oscillator.

What is the NI part number?

The listed NI part number is 785263-01.
