The NI USB-8452 connects a USB host to I2C and SPI devices. Catalog part number 781964-02 identifies the board-only OEM version without an enclosure.
Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.
Key product information and technical features.
The USB-8452 provides programmable reference voltages for interfacing with multiple logic families. Eight SPI chip-select lines and eight general-purpose digital I/O lines support peripheral selection and auxiliary digital control.
NI-845x driver software is required to operate the interface. Select a driver release appropriate for the host operating system and development environment.
Verified product specifications.
| Maximum I2C clock rate | 3.33 MHz |
|---|---|
| Maximum SPI clock rate | 50 MHz |
| Bus connection | USB 2.0 |
| Enclosed | No |
| Operating temperature | 0 to 45 °C |
| General-purpose digital I/O lines | 8 lines |
| SPI chip-select lines | 8 lines |
| Front-end connector | IDE-40; pin 20 omitted |
Confirm condition, included accessories and revision before ordering.
Confirmed per unit.
Device / accessories confirmed in quote.
Exact revision confirmed when relevant.
Review system components and compatibility requirements.
Manufacturer
Host interface
I2C/SPI interface
NI-845x
Manuals, software and technical resources for this model.
Review shipping, warranty and return terms before ordering.
Choose pricing, rental or repair for this exact model.
Product-specific answers based on available technical information.
No. The supplied catalog part number, 781964-02, corresponds to NI's board-only OEM version.
NI-845x driver software is required. NI's version 21.3 readme explicitly lists both USB-8452 and USB-8452 OEM hardware; check release-specific host compatibility before installation.
