The NI USB-6363 is an X Series USB multifunction DAQ device combining analog input, analog output, digital I/O, and counters.
Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.
Key product information and technical features.
NI-STC3 technology provides independent analog and digital timing engines and retriggerable measurement tasks.
Analog inputs share one ADC. Multichannel acquisition is multiplexed rather than simultaneous, and the 1 MS/s aggregate limit is shared across configured channels.
Verified product specifications.
| Host interface | USB 2.0 |
|---|---|
| Single-ended analog inputs | 32 channels |
| Differential analog inputs | 16 channels |
| Analog input resolution | 16 bits |
| Single-channel maximum sample rate | 2 MS/s |
| Multichannel maximum aggregate sample rate | 1 MS/s |
| Simultaneous analog input sampling | No; multiplexed ADC |
| Analog outputs | 4 channels |
| Bidirectional digital I/O | 48 channels |
Confirm condition, included accessories and revision before ordering.
Confirmed per unit.
Device / accessories confirmed in quote.
Exact revision confirmed when relevant.
Review system components and compatibility requirements.
Manufacturer
DAQ platform
Multifunction I/O device
NI documents USB-6363 operation with NI-DAQmx and LabVIEW.
Manuals, software and technical resources for this model.
Review shipping, warranty and return terms before ordering.
Choose pricing, rental or repair for this exact model.
Product-specific answers based on available technical information.
No. Signals are multiplexed into one ADC. The maximum is 2 MS/s for one channel or 1 MS/s aggregate for multichannel acquisition.
Divide the 1 MS/s aggregate maximum by the number of configured channels. NI gives approximately 166 kS/s per channel for six channels.
