USB-6000
1 image: Click to enlarge
NI (National Instruments) · USB 2.0

USB-6000

The NI USB-6000 is a bus-powered USB multifunction I/O device with 8 single-ended analog inputs, 4 bidirectional digital channels, and 1 counter/timer. Its analog inputs provide 12-bit resolution and a maximum sample rate of 10 kS/s.

ManufacturerNI (National Instruments)
ModelUSB-6000
Part Number782602-01 · 782603-01
Product Type8 AI (10 kS/s), 4 DIO USB Multifunction I/O Device
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: USB-6000

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Bidirectional Digital Channels4
Supported Power InputBus Powered
Max Single-Ended Analog Input Channels8
Number of Counters/Timers1
Analog Input Absolute Accuracy26 mV
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The USB-6000 combines analog input acquisition, digital I/O, and a counter/timer in a USB-connected device. Its eight analog inputs are single-ended, with a -10 V to 10 V input range and 12-bit resolution.

USB bus power supports a compact measurement setup without a separate device power supply. The USB-6000 does not provide analog outputs or differential analog input channels, and it does not support simultaneous sampling.

  • Eight single-ended analog inputs with 12-bit resolution and a maximum sample rate of 10 kS/s.
  • Analog input voltage range of -10 V to 10 V.
  • Four bidirectional digital channels with 5 V logic levels.
  • One counter/timer and a 2047-sample analog input FIFO buffer.
  • USB 2.0 connection with bus-powered operation.
Verified specifications

Technical data

Verified product specifications.

Number of Bidirectional Digital Channels4
Supported Power InputBus Powered
Maximum Number of Single-Ended Analog Input Channels8
Number of Counters/Timers1
Analog Input Absolute Accuracy26 mV
Analog Input FIFO Buffer Size2047 samples
Maximum Sample Rate10 kS/s
Simultaneous SamplingNo
Analog Input Resolution12 bits
Bus ConnectorUSB 2.0
ReconfigurableNo
Number of Analog Input Channels8
Operating Temperature Range0 °C to 40 °C
Bus ConnectionUSB 2.0
Digital I/O Logic Levels5 V
Maximum Clock Rate10 MHz
Signaling TypeSingle-Ended
Analog Input Voltage Range-10 V to 10 V
NI part numbers782602-01, 782603-01
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

NI

Manufacturer

USB 2.0

Bus Connector

USB-6000

This product

Platform shown as listed by NI. Confirm controller, chassis and software fit for your system with NI before integration.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

Specifications (NI)Specifications · ni.com
Open →
Dimensional Drawings (NI)Dimensional Drawings · ni.com
Open →
Product Page (NI)Product Page · ni.com
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Explore equipment

Data Acquisition and Control Systems

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

How many analog input channels does the USB-6000 have?

It has 8 single-ended analog input channels and no differential analog input channels.

What are its analog input resolution and maximum sample rate?

The USB-6000 provides 12-bit analog input resolution and a maximum sample rate of 10 kS/s. Simultaneous sampling is not supported.

Does the USB-6000 provide analog outputs?

No. It has no analog output or voltage output channels.

How does the USB-6000 connect and receive power?

It connects through USB 2.0 and receives power from the USB bus.
