National Instruments SCXI-1321 product image 1

National Instruments SCXI-1321 product image 1 additional view

4 images: additional views below.Click to enlarge

National Instruments · SCXI

SCXI-1321

The NI SCXI-1321 provides signal connections, bridge offset nulling, and strain-gauge shunt calibration for SCXI-1121 revision C or later modules.

ManufacturerNational Instruments

ModelSCXI-1321

Part Number776573-21

Product TypeOffset-null and shunt-calibration terminal block

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: SCXI-1321

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Connections18 screw terminals

Required moduleSCXI-1121, revision C or later

Bridge adjustmentManual offset nulling

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

Designed primarily for Wheatstone-bridge transducers, the SCXI-1321 connects at the module front rather than operating as a standalone acquisition device.

Independent nulling circuitry and trimming potentiometer for each channel.
Socketed shunt resistors allow selection of alternative resistance values.
Built-in cold-junction temperature sensor for thermocouple measurements.

Verified specifications

Technical data

Verified product specifications.

Screw terminals	18
Compatible module revision	SCXI-1121 revision C or later
Factory shunt resistor nominal value	301 kΩ
Factory shunt resistor tolerance	±1 %
CJC sensor output	10 mV/°C
CJC sensor accuracy	±0.9 over 0 to 55 °C °C

Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

SCXI-1121

Host module; revision C or later required

SCXI-1321

Front-mounted terminal block

Compatibility

Supported with SCXI-1121 revision C or later only.

Verify the SCXI-1121 hardware revision before selecting this terminal block.

Manuals & software

Technical resources

Manuals, software and technical resources for this model.

SCXI-1321 Offset-Null and Shunt-Calibration High-Voltage Terminal Block Installation GuideInstallation Guide · download.ni.com

Open →

SCXI-1121 User ManualUser Manual · download.ni.com

Open →

Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping

Free Shipping. Full policy terms apply.

Warranty

30-Day Warranty. Standard coverage applies.

Returns

30-Day Returns. Return policy applies.

Price / Availability

Contact SOHO ProLab for current quote and availability.

Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Explore equipment

SCXI

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Which module accepts the SCXI-1321?

The SCXI-1121, revision C or later.

Can it connect RTDs and thermistors?

Yes, with appropriate excitation configuration. Disable the relevant nulling circuit when using current excitation; follow the installation guide.

Are the shunt switches independently controlled?

No. The channel circuits are independent, but their shunt switches are controlled together in software.
