The National Instruments SCXI-1301 is a 20-screw-terminal block for connecting signals to supported SCXI modules, including the SCXI-1140.
Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.
Key product information and technical features.
The SCXI-1301 provides screw-terminal signal access at the front of an SCXI module. Its SCXI-1140 connections include differential inputs, analog ground, HOLD, and functional chassis ground.
NI also documents the SCXI-1301 as a signal breakout for the SCXI-1181 when using its 96-pin front connector. Unlike the SCXI-1300, the SCXI-1301 has no onboard temperature sensor.
Verified product specifications.
| Screw terminals | 20 terminals |
|---|---|
| SCXI-1140 differential input connections | 8 pairs |
| Analog ground connections | 2 terminals |
| Additional connections | HOLD and functional chassis ground |
| Onboard temperature sensor | None |
Confirm condition, included accessories and revision before ordering.
Confirmed per unit.
Device / accessories confirmed in quote.
Exact revision confirmed when relevant.
Review system components and compatibility requirements.
Manufacturer
Module platform
Front-mounted terminal block
Documented breakout option with the module's 96-pin front connector.
Manuals, software and technical resources for this model.
Review shipping, warranty and return terms before ordering.
Choose pricing, rental or repair for this exact model.
Product-specific answers based on available technical information.
Yes. NI documents it as a signal breakout when the SCXI-1181 uses its 96-pin front connector.
No. NI explicitly states that the SCXI-1301 has no temperature sensor.
