National Instruments SC-2053 DAQ signal conditioning cable adapter
1 image: Click to enlarge
National Instruments · Lab/1200 Series

SC-2053

The National Instruments SC-2053 is a cable adapter that routes Lab/1200 Series DAQ connector signals to standard connections for signal conditioning accessories. It provides two 50-pin connectors and four 26-pin accessory connectors.

ManufacturerNational Instruments
ModelSC-2053
Product TypeDAQ signal conditioning cable adapter
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: SC-2053

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Host platformLab/1200 Series DAQ devices
Host connectorsTwo 50-pin connectors connected pin-by-pin
Accessory connectorsFour 26-pin ribbon-cable connectors
Accessory interfaces5B analog conditioning, SC-206X digital conditioning and 8-channel SSR backplanes
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The SC-2053 adapts Lab/1200 Series I/O wiring for external signal conditioning. Either 50-pin connector can provide the host connection; the second supports daisy-chaining to another 50-pin accessory.

  • Analog accessory ports use pin connections compatible with 5B Series conditioning modules.
  • Digital accessory ports support SC-206X conditioners and 8-channel SSR boards.
  • Metal standoffs support placement on a workbench near the host computer.
Verified specifications

Technical data

Verified product specifications.

Host cableType NB1, 50-pin ribbon cable
SC-206X and 5B accessory cableType NB7, 26-pin ribbon cable
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

Lab/1200 Series

Host DAQ platform

SC-2053

Cable adapter

Compatibility

Designed for Lab/1200 Series DAQ devices; consult Table 1-1 of the NI manual for the supported device list.

Power off the host before connecting. NI warns that connection to an unsupported DAQ board can damage the adapter, connected equipment and host.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

SC-205X Series User Manual — November 1998, Chapter 5: SC-2053User Manual · docs-be.ni.com
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Is the SC-2053 a matrix switch?

NI documents the SC-2053 as a Lab/1200 Series cable adapter for signal conditioning accessories, not as a matrix switch.
