NI (National Instruments) sbRIO-9871 Non-Enclosed, 4-Port, RS485/RS422 C Series Serial Instrument Control Module
1 image: Click to enlarge
NI (National Instruments) · CompactRIO

sbRIO-9871

The NI sbRIO-9871 is a non-enclosed, four-port RS485/RS422 C Series serial instrument control module. It supports a maximum baud rate of 3.68 Mbits/s.

ManufacturerNI (National Instruments)
ModelsbRIO-9871
Part Number780879-10
Product TypeNon-Enclosed, 4-Port, RS485/RS422 C Series Serial Instrument Control Module
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: sbRIO-9871

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Supported Serial ProtocolsRS422
Supported Hardware PlatformCompactRIO
Maximum Baud Rate3.68 Mbits/s
Operating Temperature Range-40 °C to 85 °C
Front Connection TypeRJ50
Isolation TypePort-to-earth ground
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The sbRIO-9871, NI part number 780879-10, provides four serial channels with RJ50 front connections and port-to-earth ground isolation. It belongs to NI's C Series serial instrument control module family.

Serial ports are accessed directly from the FPGA, and individual buffers on every port help save FPGA space and simplify programming. This version is non-enclosed and is not conformal coated.

  • Provides four serial channels.
  • Supports a maximum baud rate of 3.68 Mbits/s.
  • Uses RJ50 front connections.
  • Provides port-to-earth ground isolation.
  • Operates over a temperature range of -40 °C to 85 °C.
  • Non-enclosed construction without conformal coating.
Verified specifications

Technical data

Verified product specifications.

Supported Serial ProtocolsRS422
Conformal CoatedNo
EnclosedNo
Supported Hardware PlatformCompactRIO
Maximum Baud Rate3.68 Mbits/s
Operating Temperature Range-40 °C to 85 °C
Front Connection TypeRJ50
Isolation TypePort-to-earth ground
Number of Serial Channels4
NI part numbers780879-10
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

NI

Manufacturer

CompactRIO

Supported Hardware Platform

sbRIO-9871

This product

Platform shown as listed by NI. Confirm controller, chassis and software fit for your system with NI before integration.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

Dimensional Drawings (NI)Dimensional Drawings · ni.com
Open →
Product Page (NI)Product Page · ni.com
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

FAQ

Product-specific questions

Product-specific answers based on available technical information.

How many serial channels does the sbRIO-9871 provide?

The sbRIO-9871 provides four serial channels.

What is the maximum baud rate?

The specified maximum baud rate is 3.68 Mbits/s.

What type of front connection does it use?

The sbRIO-9871 uses RJ50 front connections.

Is the sbRIO-9871 enclosed or conformal coated?

No. This version is non-enclosed and is not conformal coated.

What is the operating temperature range?

The specified operating temperature range is -40 °C to 85 °C.
