National Instruments sbRIO-9211 Non-enclosed thermocouple temperature input module
1 image: Click to enlarge
National Instruments · Single-Board RIO / CompactRIO

sbRIO-9211

The NI sbRIO-9211 is a board-only, four-channel thermocouple input module with 24-bit conversion and a ±80 mV measurement range.

ManufacturerNational Instruments
ModelsbRIO-9211
Part Number780877-01
Product TypeNon-enclosed thermocouple temperature input module
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: sbRIO-9211

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Thermocouple inputs4 differential channels
Resolution24-bit
Input range±80 mV
ConstructionNon-enclosed; no conformal coating
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

Designed for OEM integration, the sbRIO-9211 provides temperature inputs in a non-enclosed C Series format. It includes cold-junction compensation, anti-aliasing filters and open-thermocouple detection.

  • Supports J, K, T, E, N, B, R and S thermocouples.
  • Scanned delta-sigma analog-to-digital conversion.
  • Screw-terminal sensor connections.
Verified specifications

Technical data

Verified product specifications.

Thermocouple input channels4 channels
ADC resolution24 bits
Voltage measurement range-80 to +80 mV
Sampling modeScanned
Conversion time70 per channel; 420 total including autozero and cold-junction channels ms
Channel-to-channel isolationNone
Continuous channel-to-earth isolation250; Measurement Category II Vrms
EnclosedNo
Conformal coatingNo
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

Single-Board RIO

Board-level hardware ecosystem

sbRIO-9211

C Series temperature input module

Supported hardware platform

CompactRIO

Confirm controller support and board-level mounting requirements before integration; the catalog's CompactDAQ category is not compatibility evidence.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

sbRIO-9211 Product PageProduct Page · ni.com
Open →
NI-9211 and sbRIO-9211 SpecificationsSpecifications · ni.com
Open →
sbRIO-9211 Dimensional DrawingsDimensional Drawings And CAD Models · ni.com
Open →
sbRIO-9211 Mechanical Drawings and CAD DownloadsTechnical resource
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Explore equipment

CompactDAQ

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Which part number identifies the board-only sbRIO-9211?

NI's Single-Board RIO hardware table identifies 780877-01 as the NI 9211E board-only thermocouple and differential analog input module under model sbRIO-9211.

Are the thermocouple channels isolated from one another?

No. NI specifies channel-to-earth isolation, but no channel-to-channel isolation.
