PXIe-4310

Name: PXIe-4310
Brand: NI (National Instruments)

The NI PXIe-4310, part number 784813-01, is a PXI Express voltage input module with 8 differential channels, 16-bit resolution and simultaneous sampling up to 400 kS/s per channel. It provides 600 V channel-to-channel isolation and selectable input ranges from ±1 V to ±600 V.

ManufacturerNI (National Instruments)

ModelPXIe-4310

Part Number784813-01

Product Type16-Bit, 8-Channel, 400 kS/s/ch, Ch-Ch Isolated PXI Analog Input Module

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: PXIe-4310

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Maximum Sample Rate400 kS/s/ch

Analog Input Voltage Range-1 V to 1 V, -2 V to 2 V, -5 V to 5 V, -10 V to 10 V, -60 V to 60 V

Analog Input Voltage Range (cont. 2)-120 V to 120 V, -300 V to 300 V, -600 V to 600 V

Analog Input Isolation600 V Ch-Ch Isolation

Max Differential Analog Input Channels8

Analog Input Resolution16 bits

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

The PXIe-4310 fits into a PXI Express measurement system as an isolated voltage acquisition module. Its 8 differential inputs sample simultaneously at up to 400 kS/s per channel, with 16-bit resolution and 600 V channel-to-channel isolation.

Eight selectable bipolar input ranges cover ±1 V through ±600 V. Per-channel analog filter selection provides Butterworth low-pass filtering with 10 kHz and 100 kHz settings.

8 differential voltage input channels with 16-bit resolution.
Simultaneous sampling up to 400 kS/s per channel, using an A/D converter for each channel.
600 V channel-to-channel isolation.
Eight selectable input ranges: ±1, ±2, ±5, ±10, ±60, ±120, ±300 and ±600 V.
Per-channel Butterworth low-pass filter selection with 10 kHz and 100 kHz settings.
PXI Express bus connection and DIN front connection.

Verified specifications

Technical data

Verified product specifications.

Maximum Sample Rate	400 kS/s/ch
Analog Input Voltage Range	-1 V to 1 V, -2 V to 2 V, -5 V to 5 V, -10 V to 10 V, -60 V to 60 V
Analog Input Voltage Range (cont. 2)	-120 V to 120 V, -300 V to 300 V, -600 V to 600 V
Analog Input Isolation	600 V Ch-Ch Isolation
Maximum Number of Differential Analog Input Channels	8
Analog Input Resolution	16 bits
Discrete Low-Pass Filter	10 kHz, 100 kHz
Filtering	Butterworth
Bus Connection	PXI Express
Simultaneous Sampling	Yes
Analog Input Absolute Accuracy	2495 μV
Front Connection Type	DIN
Operating Temperature Range	0 °C to 55 °C
NI part numbers	784813-01
