National Instruments · PXI

PXI-8186

The NI PXI-8186 is a 2.2 GHz embedded PXI/CompactPCI controller with integrated peripheral interfaces.

ManufacturerNational Instruments

ModelPXI-8186

Product TypeEmbedded system controller

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: PXI-8186

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

Processor clock2.2 GHz

USBTwo USB 2.0 ports

Ethernet10/100

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

Combines PC functionality and instrument connectivity within a 3U PXI controller assembly.

Integrated PCI-based GPIB controller.
Two RS-232 ports.
VGA, parallel and PS/2 connections.

Verified specifications

Technical data

Verified product specifications.

Processor clock	2.2 GHz
Slot requirements	One system slot plus three controller expansion slots
Memory type	PC2100 DDR SDRAM SO-DIMM

Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

PXI/CompactPCI

System platform

PXI-8186

Embedded controller

Compatibility

NI documents installation in the PXI-1042 chassis.

Confirm chassis space and legacy software support before integration.

Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI PXI-8186/8187 User Manual and SpecificationsUser Manual · download.ni.com

Open →

NI PXI-8186 Installation GuideInstallation Guide · download.ni.com

Open →

PXI Platform Services 20.0 Readme — deprecated hardwareTechnical resource

Open →

Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping

Free Shipping. Full policy terms apply.

Warranty

30-Day Warranty. Standard coverage applies.

Returns

30-Day Returns. Return policy applies.

Price / Availability

Contact SOHO ProLab for current quote and availability.

Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Explore equipment

PXI Platform

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Is the PXI-8186 the 2.5 GHz model?

No. NI specifies 2.2 GHz for the PXI-8186; 2.5 GHz identifies the PXI-8187.

Do recent PXI Platform Services releases necessarily support it?

No. The PXI Platform Services 20.0 readme lists the PXI-8186 under deprecated hardware support. Check version-specific requirements.
