The NI PXI-7953 is a FlexRIO FPGA module featuring a Virtex-5 LX85 FPGA and 128 MB of DRAM. It provides customizable I/O for LabVIEW FPGA.
Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.
Key product information and technical features.
The PXI-7953 supplies the programmable FPGA portion of a modular FlexRIO system. A FlexRIO adapter module defines the physical inputs and outputs and connects through the FPGA module's card-edge interface.
NI's support catalog uses PXI-7953, while its installation guide and FPGA comparison tables use PXI-7953R. The published LX85 FPGA and 128 MB DRAM configuration matches the supplied catalog record.
Verified product specifications.
| FPGA | Virtex-5 LX85 |
|---|---|
| FPGA slices | 12960 slices |
| DSP48 slices | 48 slices |
| Embedded block RAM | 3456 kbit |
| Onboard DRAM | 128 MB |
| DMA channels | 3 channels |
| Default timebase | 40 MHz |
| Timebase reference | PXI_CLK10 |
| I/O connector | High-density card edge |
Confirm condition, included accessories and revision before ordering.
Confirmed per unit.
Device / accessories confirmed in quote.
Exact revision confirmed when relevant.
Review system components and compatibility requirements.
Manufacturer
Modular instrumentation platform and product family
Programmable FPGA module
Defined by the attached FlexRIO adapter module.
Manuals, software and technical resources for this model.
Review shipping, warranty and return terms before ordering.
Choose pricing, rental or repair for this exact model.
Product-specific answers based on available technical information.
NI identifies the PXI-7953 with a Virtex-5 LX85 FPGA and 128 MB of DRAM.
NI's support listing uses PXI-7953, while its FlexRIO comparison table and installation guide identify the matching configuration as PXI-7953R.
The attached FlexRIO adapter module defines the physical inputs and outputs. Check its documentation for signal types and connections.
