The NI PXI-7352 is a two-axis PXI stepper/servo motion controller with sinusoidal commutation for brushless servo control.
Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.
Key product information and technical features.
The PXI-7352 supports blended trajectories and coordinated linear, circular, point-to-point, gearing and vector-space control. NI describes operation in embedded real-time and host-centric programming environments.
The NI 7350 hardware manual documents motor command outputs, encoder feedback, home and limit inputs, position-compare outputs and position-capture inputs. Consult its signal-connection chapter when planning drive and feedback wiring.
Verified product specifications.
| Number of axes | 2 axes |
|---|---|
| Supported motor types | Stepper; brushed servo; brushless servo |
| Analog-to-digital converters | 8 converters |
| Analog input resolution | 16 bits |
| Digital I/O channels | 64 channels |
| External I/O connector type | 68-pin female VHDCI |
| Circuit isolation | No isolation between circuits |
Confirm condition, included accessories and revision before ordering.
Confirmed per unit.
Device / accessories confirmed in quote.
Exact revision confirmed when relevant.
Review system components and compatibility requirements.
Manufacturer
Hardware platform
Motion controller family
Two-axis controller
Manuals, software and technical resources for this model.
Review shipping, warranty and return terms before ordering.
Choose pricing, rental or repair for this exact model.
Product-specific answers based on available technical information.
It controls two axes, not the eight axes provided by the PXI-7358.
NI specifies NI-Motion. Check the selected driver release's host and firmware requirements before integration.
Chapter 5, Signal Connections, of the NI 7350 User Manual documents the motion and digital I/O connectors.
