The National Instruments PXI-6542 is a PXI digital waveform instrument with a maximum clock rate of 100 MHz and selectable 1.8 V, 2.5 V, and 3.3 V logic levels.
Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.
Key product information and technical features.
The PXI-6542 belongs to NI's digital waveform instrument family for digital interfacing and functional test. Its selectable logic levels support working with different digital voltage domains.
NI documents the PXI-6542 under NI-HSDIO hardware support and its 68-pin VHDCI cable and accessory group. Connection planning should follow the model-specific accessory guide rather than connector appearance alone.
Verified product specifications.
| Maximum clock rate | 100 MHz |
|---|---|
| Maximum data rate | 100 Mbit/s |
| Selectable logic levels | 1.8, 2.5, 3.3 V |
| Digital connector | 68-pin VHDCI |
Confirm condition, included accessories and revision before ordering.
Confirmed per unit.
Device / accessories confirmed in quote.
Exact revision confirmed when relevant.
Review system components and compatibility requirements.
Manufacturer
Instrumentation platform
Digital waveform instrument
NI-HSDIO; verify the required driver release against the target operating system.
Manuals, software and technical resources for this model.
Review shipping, warranty and return terms before ordering.
Choose pricing, rental or repair for this exact model.
Product-specific answers based on available technical information.
NI specifies a maximum clock rate of 100 MHz and selectable logic levels of 1.8 V, 2.5 V, and 3.3 V.
NI lists the SHC68-C68-D4 as the recommended shielded cable for the 6542 group. Review the accessory guide for termination options and connection limitations.
The NI-HSDIO 15.0 readme explicitly lists the NI PXI/PCI-6542 as supported hardware. This historical reference does not establish compatibility with every later operating system or driver release.
