PXI-2585

The NI PXI-2585 is a 10-channel, 12 A, 1-wire PXI multiplexer switch module with electromechanical relays and a PXI Hybrid bus connection.

ManufacturerNI (National Instruments)
ModelPXI-2585
Part Number778572-85
Product Type10‐Channel, 12 A, 1-Wire PXI Multiplexer Switch Module
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: PXI-2585

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Scan Rate65 cycles/s
Mode (n-wire)1-wire
Bus ConnectorPXI Hybrid
Maximum Switching Current DC12 A
Maximum Switching Voltage DC300 V
Relay TypeElectromechanical
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The PXI-2585 is a high-power PXI multiplexer switch module for switching power signals and loads in control applications and battery, power supply, and automotive testing.

It is configured as a 10 × 1 multiplexer with low contact resistance, high isolation voltage, onboard relay counting, and hardware-triggered deterministic operation.

  • 10-channel, 1-wire multiplexer with one bank, one column, and 10 rows.
  • Maximum DC switching current of 12 A and maximum AC carry current of 12 A.
  • Maximum switching voltage of 300 V for AC and DC.
  • 10 MHz switch bandwidth and a scan rate of 65 cycles/s.
  • Electromechanical relays with 10 crosspoints.
  • PXI Hybrid bus connection with row access and termination.
Verified specifications

Technical data

Verified product specifications.

Scan Rate65 cycles/s
Mode (n-wire)1-wire
Bus ConnectorPXI Hybrid
Maximum Switching Current DC12 A
Maximum Switching Voltage DC300 V
Relay TypeElectromechanical
Switch Bandwidth10 MHz
Number of Channels10
Number of Banks1
Supported Hardware PlatformPXI
Bus ConnectionPXI Hybrid
Crosspoints10
Maximum Carry Current AC12 A
Maximum Switching Voltage AC300 V
Number of Columns1
Number of Rows10
Row AccessYes
TerminationYes
NI part numbers778572-85
