National Instruments PCIe-8253 FireWire camera interface board
1 image: Click to enlarge
National Instruments · PCI Express

PCIe-8253

The National Instruments PCIe-8253 is a PCI Express interface board for FireWire cameras. It provides three IEEE 1394b ports with up to 18 W of IEEE 1394 bus power shared across all ports.

ManufacturerNational Instruments
ModelPCIe-8253
Part Number781107-01
Product TypeFireWire camera interface board
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: PCIe-8253

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Host platformPCI Express
Camera interfaceIEEE 1394b (FireWire)
Camera ports3
Shared bus power18 W maximum across all ports
