National Instruments PCIe-1473 Reconfigurable Camera Link frame grabber
1 image: Click to enlarge
National Instruments · PCI Express

PCIe-1473

The NI PCIe-1473 is a PCI Express Camera Link frame grabber with a user-programmable FPGA for onboard image processing. It supports Power over Camera Link for powering compatible cameras through PoCL-enabled cables.

ManufacturerNational Instruments
ModelPCIe-1473
Product TypeReconfigurable Camera Link frame grabber
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: PCIe-1473

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Camera interfaceCamera Link, including Full configuration
Host interfacePCI Express x4
FPGA optionsVirtex-5 LX50 or LX110; installed variant requires confirmation
Camera powerPower over Camera Link supported
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The PCIe-1473 places a programmable FPGA directly in the image path. NI describes its use for image acquisition and processing with closed-loop control without CPU intervention, or for preprocessing image data before transferring it to the host CPU.

NI documentation uses PCIe-1473R for the LX50 hardware and PCIe-1473R-LX110 for the larger FPGA variant. This catalog retains the PCIe-1473 identity; confirm the board label before selecting variant-specific resources.

  • User-programmable FPGA supports onboard image processing.
  • Supports Base, Medium, Full, and Extended Full Camera Link configurations.
  • PoCL is enabled by default on PCIe-1473R hardware.
Verified specifications

Technical data

Verified product specifications.

Camera interfaceCamera Link - Full
PCI Express interfaceRevision 1.1, x4 native link
Camera connectorsTwo 26-pin MDR connectors
Supported cameras1 camera
Pixel clock frequency20–85 MHz
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

PCI Express

Host computer expansion interface

PCIe-1473

Reconfigurable Camera Link image acquisition

Camera power

Use a PoCL-compatible camera and PoCL-supported cable when powering through Camera Link.

Confirm the installed FPGA variant and camera configuration; two connectors do not indicate support for two independent cameras.
Manuals & software

Technical resources

Manuals, software and technical resources for this model.

NI PCIe-1473 Product Support and Variant DetailsOfficial Product Page · ni.com
Open →
NI PCIe-1473R User Guide and SpecificationsLX50 Hardware Manual · download.ni.com
Open →
NI PCIe-1473R-LX110 User Guide and SpecificationsLX110 Variant Manual · docs-be.ni.com
Open →
How to Enable Power over Camera Link on NI Frame GrabbersTechnical resource
Open →
Shipping, warranty & returns

Commercial terms

Review shipping, warranty and return terms before ordering.

Shipping
Free Shipping. Full policy terms apply.
Warranty
30-Day Warranty. Standard coverage applies.
Returns
30-Day Returns. Return policy applies.
Price / Availability
Contact SOHO ProLab for current quote and availability.
Lifecycle services

Source, rent or repair the exact model

Choose pricing, rental or repair for this exact model.

Get Price

Current price, availability and exact unit details.

Rent This Model

Request the exact model or a suitable alternative.

Repair This Model

Send the model and failure symptoms for review.

Explore equipment

Data Acquisition and Control Systems

Shipping, warranty and returns

FAQ

Product-specific questions

Product-specific answers based on available technical information.

Do the two Camera Link connectors support two cameras?

NI lists support for one camera. Base uses Port 0; Medium, Full, and Extended Full use both connectors for the same camera.

Is the LX50 FPGA confirmed for this catalog record?

No. The legacy description specifies LX50, but NI lists both LX50 and LX110 variants under PCIe-1473. Confirm the physical board identification.

Must PoCL be enabled through a camera file?

NI states that PCIe-1473R has PoCL enabled by default and does not require editing an .icd file to enable it. The camera and cable must support PoCL.
