National Instruments · PCI

PCI-7030/6533E

This catalog record identifies an NI PCI-7030/6533E RT Series board. NI documents the PCI-7030/6533 digital I/O configuration without the E suffix; confirm the board label before applying those specifications to this item.

ManufacturerNational Instruments

ModelPCI-7030/6533E

Product TypeRT Series digital I/O plug-in board; exact catalog suffix requires verification

● Available to Order

Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: PCI-7030/6533E

Free Shippingfull policy linked

30-Day Warrantystandard coverage

30-Day Returnspolicy applies

Technical Supportmodel & compatibility help

PlatformPCI RT Series

Documented configurationPCI-7030/6533; catalog E suffix not confirmed

Documented digital I/O32 input/output channels on the 7030/6533 configuration

Documented logic compatibilityTTL/CMOS, standard or open collector

SOHO Assistant

Ask about this exact model, a replacement, accessory, driver, rental or repair question.

Ask about specifications, compatibility, availability, rental or repair.

Ask SOHO Assistant

Overview

Product overview

Key product information and technical features.

NI's archived specifications explicitly cover the PCI/PXI-7030/6533 configuration. Its digital interface provides 32 input/output channels, four dedicated output/control lines, and four dedicated input/status lines. These are specifications for the manufacturer-documented configuration, not confirmation of the catalog's E-suffixed identity.

The PCI/PXI-7030 platform belongs to NI's legacy LabVIEW Real-Time environment. NI's release notes explain that LabVIEW RT and NI-DAQ versions must be matched because NI-DAQ is used both on the host PC and in the RT Engine. Check the existing system's software versions before planning integration.

The documented 7030/6533 configuration provides a 32-channel digital input/output interface.
Dedicated control and status lines supplement the documented configuration's data channels.
NI's 7030 real-time boards support host-to-RT Engine communication through Shared Memory VIs.

Verified specifications

Technical data

Verified product specifications.

Digital I/O channels — documented PCI-7030/6533	32 channels
Dedicated output/control lines — documented PCI-7030/6533	4 lines
Dedicated input/status lines — documented PCI-7030/6533	4 lines
Logic compatibility — documented PCI-7030/6533	TTL/CMOS, standard or open collector
