The National Instruments PCI-6551 is a 50 MHz, 20-channel digital waveform generator/analyzer for PCI systems. It supports per-channel, per-cycle bidirectional control.
Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.
Key product information and technical features.
NI-HSDIO identifies the PCI-6551 as a digital waveform generator/analyzer. Its stimulus-response capabilities include real-time comparison of acquired data against expected responses.
Verified product specifications.
| Data channels | 20 channels |
|---|---|
| Maximum sample clock frequency | 50 MHz |
| Generation voltage range | -2.0 to 5.5 into 1 MΩ; level-pair and swing restrictions apply V |
| Generation level resolution | 10 mV |
| Maximum data channel toggle rate | 25 MHz |
| Digital data connector | 68-pin VHDCI |
Confirm condition, included accessories and revision before ordering.
Confirmed per unit.
Device / accessories confirmed in quote.
Exact revision confirmed when relevant.
Review system components and compatibility requirements.
Manufacturer
Host platform
Digital waveform generator/analyzer
NI-HSDIO lists PCI-6551 among supported devices.
Manuals, software and technical resources for this model.
Review shipping, warranty and return terms before ordering.
Choose pricing, rental or repair for this exact model.
Product-specific answers based on available technical information.
NI-HSDIO supports the PCI-6551. Check the readme for the intended driver release to establish operating-system and development-environment support.
No. Generation channels share one low and one high level; acquisition channels share a separately configurable threshold pair.
The installed capacity is unspecified. NI documents 1, 8, and 64 Mbit/channel variants.
