National Instruments SCB-68A Shielded screw-terminal I/O connector block
1 image: Click to enlarge
National Instruments · NI DAQ and supported R Series devices

NI SCB-68A

The NI SCB-68A provides shielded screw-terminal connections for compatible NI data acquisition devices. It is a breakout accessory, not an acquisition device or an electronic isolation module.

ManufacturerNational Instruments
ModelSCB-68A
Part Number782536-01
Product TypeShielded screw-terminal I/O connector block
● Available to Order
Condition: confirmed per unit

Request current pricing and lead time for this model. Our team will confirm the exact equipment configuration and condition.

Fast RFQ

Quote: SCB-68A

We will reply by email.
Free Shippingfull policy linked
30-Day Warrantystandard coverage
30-Day Returnspolicy applies
Technical Supportmodel & compatibility help
Manufacturer part number782536-01
Termination68 screw terminals
ShieldingEMI shielding when used with a shielded cable
Electrical isolationNot provided
SOHO Assistant
Ask about this exact model, a replacement, accessory, driver, rental or repair question.
Ask about specifications, compatibility, availability, rental or repair.
Ask SOHO Assistant
Overview

Product overview

Key product information and technical features.

The SCB-68A belongs to NI's shielded connector-block family, providing screw-terminal access inside a shielded enclosure. Device and cable selection must follow NI's accessory compatibility guidance rather than connector pin count alone.

The board supports user-added circuitry but does not supply built-in signal conditioning. Its shielding does not electrically isolate field wiring from the connected DAQ device.

  • Shielded enclosure with screw-terminal signal connections.
  • Breadboard area and through-hole pads for custom circuitry.
  • Onboard temperature sensor for thermocouple cold-junction compensation with appropriate DAQ configuration.
  • DIN rail mounting supported with a separate mounting kit.
Verified specifications

Technical data

Verified product specifications.

I/O connectorOne 68-pin male SCSI connector
Screw terminals68; all I/O signals accessible
Wire gauge14–30 AWG
Terminal tightening torque0.5–0.6 N·m
Dimensions including feet14.7 × 14.7 × 3.0 cm
Weight644 g
Temperature sensor accuracy±1.0 over 0 to 70 °C °C
Maximum input voltage30 Vrms / 42 Vpk / 60 VDC; connected device limits also apply
Condition & included items

What the actual unit includes

Confirm condition, included accessories and revision before ordering.

Condition

Confirmed per unit.

Included

Device / accessories confirmed in quote.

Revision

Exact revision confirmed when relevant.

Compatibility

Complete the measurement chain

Review system components and compatibility requirements.

National Instruments

Manufacturer

NI DAQ accessories

Device-specific cabling and signal termination

SCB-68A

Shielded screw-terminal breakout

R Series configuration

Supported R Series connections require the correct cable and device-specific terminal pinout.

Verify the exact DAQ model, connector, cable, pinout and switch configuration before wiring.
